Omron SYSMAC CS1 User Manual

4-4SectionLR Area
54
4-4-2 Unit Setup Area
Bit
Area for input words in the CPU Unit
Number of input words (BCD)
First word address of input words in the CPU Unit (BCD)
Area for output words in the CPU Unit Number of output words (BCD)
First word address of output words in the CPU Unit (BCD)
15 08 07 00
DM6601
DM6602
DM6603
DM6604
Settings
Function Address Bit Contents
Input refresh (for
input from the
C
DM 6601
00 to 07 Number of refresh
words
00 (BCD): Not refreshed
01 to 32 (BCD): 1 to 32 words
oe
CPU Unit to the
Customizable
Counter Unit)
08 to 15 CPU Unit area 00 (BCD): CIO
01 (BCD): WR
02 (BCD): AR
03 (BCD): HR
04 (BCD): DM
05 (BCD): EM
Output refresh (for
output from the
C
DM 6602
00 to 07 Number of refresh
words
00 (BCD): Not refreshed
01 to 32 (BCD): 1 to 32 words
ooe
Customizable
Counter Unit to
the CPU Unit)
08 to 15 CPU Unit area 00 (BCD): CIO
01 (BCD): WR
02 (BCD): AR
03 (BCD): HR
04 (BCD): DM
05 (BCD): EM
Input refresh DM 6603 00 to 15 First word
address of CPU
Unit area
0000 to 9999 (BCD): 0 to 9999
Output refresh DM 6604 00 to 15 First word
address of CPU
Unit area
0000 to 9999 (BCD): 0 to 9999
4-4-3 Example
For the configuration shown previously, set the Unit Setup Area as shown below.
Sets the area for the input words in the CPU Unit to DM
Area (04 BCD), and sets its size to 10 words (BCD).
Sets the area for the output words in the CPU Unit to
WR Area (01 BCD), and sets its size to 20 words (BCD).
Sets the first word address for input words in the CPU
Unit to 0100 (BCD).
Sets the first word address for output words in the CPU
Unit to 300 (BCD).
Bit
04 10
15 08 07 00
01 00
03 00
DM6601
DM6602
DM6603
DM6604
01 20
