9-3SectionTroubleshooting Tables
132
Error Meaning and corrective measuresError
flags
SR 23500
to
SR 23507
Error log
(SIOU code,
details 1,
details 2)
Error
message
Unit indicatorsError Meaning and corrective measuresError
flags
SR 23500
to
SR 23507
Error log
(SIOU code,
details 1,
details 2)
Error
message
ERHERCOPNRUN
No END Lit OFF Lit OFF NO END
INST
0360 Hex
00 Hex
F0 Hex
F0 Hex SR 23511 END(01) is not written anywhere in
program.
Write END(01) at the final address of
the program.
Unit
system
error
(FALS)
Lit OFF Lit OFF SYS FAIL
FALS**
0360 Hex
00 Hex
FALS No. (1
to 99 BCD)
FALS No.
(1 to 99
BCD)
SR 23511 An FALS(07) instruction has been
executed in the program.
Check the FALS number to determine
the conditions that would cause
execution, correct the cause, and
clear the error.
Unit cycle
time
monitor
error
Lit OFF Lit OFF SYS FAIL
FALS9F
0360 Hex
00 Hex
F9 Hex
F9 Hex SR 23511 The cycle time has exceeded the
FALS 9F Cycle Time Monitoring Time
(DM 6618).
Check the cycle time and adjust the
Cycle Time Monitoring Time if
necessary.
CPU Errors Resulting in Customizable Counter Unit Fatal Errors
Error
Unit indicators
Error
messa
g
e
Error log
(
SIOU code,
SR 23500
to
Error
fla
g
s
Meaning and corrective measures
RUN OPN ERC ERH
me age
(SIOU
code
,
details 1,
details 2)
to
SR 23507
flag
Unit
recognition
error
OFF OFF Lit Lit --- --- --- --- The Customizable Counter Unit is not
recognized as a Special I/O Unit by
the CPU Unit.
Try to power-up again.
Unit not
recognized
OFF OFF OFF Lit --- 0006 Hex
08 Hex
00 Hex
--- --- The actual I/O tables do not agree
with the registered I/O tables.
Recreate the I/O tables in the CPU
Unit.
Unit
number
error
OFF OFF OFF Lit --- --- --- --- The unit number is not set correctly
or the same number has been set for
another Unit.
Correct the unit numbers and try to
power-up again.
Unit setting
read error
OFF OFF OFF Lit --- --- --- --- No response to a FINS command or
CPU settings could not be read.
Try to power-up again.
Bus error OFF OFF OFF Lit --- --- --- --- The access right could not be
obtained.
Try to power-up again.
