Onkyo A-9000R User Manual

23
En
Use the MM/MC selector on the back of the integrated amplifier to select either MM or MC,
in accordance with the cartridge format of the turntable.
Remove the short pins plugged into the jacks before connecting a turntable to the PHONO
inputs.
Note
• Always turn off the integrated amplifier before switching between MM and MC.
Tip
• If your turntable has a built-in phono preamp, you can connect the turntable to other analog inputs such
as LINE IN 1.
• If your turntable has a ground wire, connect it to the GND screw. With some turntables, connecting the
ground wire may produce an audible hum. If this happens, disconnect it.
Tip
• Connect your cassette tape deck to either of the following jacks: LINE IN 1/2/3.
Connecting a Turntable
L
R
AUDIO
OUTPUT
Turntable without a built-in
phono preamp
Integrated Amplifier A-9000R
MM/MC selector
Connecting a Cassette Tape Deck
AUDIO
OUT
L R
Integrated Amplifier A-9000R
Cassette tape deck

Onkyo A-9000R Specifications

General

Output level	0.001 mV
Damping factor	130
Amplifier class	-
Frequency range	1 - 250000 Hz
Output impedance	300 Ω
Input sensitivity	150 mV
Audio output channels	- channels
Peak power per channel	140 W
Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.05 %
Dynamic power per channel (2 Ohm)	310 W
Dynamic power per channel (3 Ohm)	230 W
Dynamic power per channel (4 Ohm)	180 W
Dynamic power per channel (8 Ohm)	100 W
AC (power) in	Yes
Audio (L/R) in	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	300 W
Package weight	22500 g

Weight and Dimensions

Width	435 mm
Height	175 mm
Weight	18500 g
