35
En
Using the Integrated Amplifier as a USB Audio Device
Using the USB port on the rear panel of the A-9000R, you
can connect your PC and play back 192 kHz/24-bit HD
audio formats.
To playback the audio data stored on your PC by using the
equipment via USB port connection, you must install the
driver on your PC from the following URL:
http://www.eu.onkyo.com (for the European customer)
http://www.intl.onkyo.com/downloads/software/index.html
(for the other area customer)
For the installation procedure, see the above Onkyo Web
site.
Operating with the remote controller
Operating on the integrated amplifier
Note
Depending on the audio player software used, the sound of
incompatible file formats may not be output.
If you unplug the USB cable, the message “USB” flashes on the
information display.
If the USB connector of your PC does not support the high-speed
2.0 standard, the audio will not be output.
If there is no USB connection between the PC and the integrated
amplifier, the “USB” input can’t be selected.
System Requirements (PC)
Windows and the Windows logo are trademarks of the
Microsoft group of companies.
Connecting a PC
Installing USB drivers
PC
USB
Playing Music Files from the PC
1
Press INPUT!/" repeatedly to switch the input
to “USB”.
2
Play music files from the PC.
1
Use the INPUT selector to switch the input to
“USB”.
2
Play music files from the PC.
INPUT !/"
INPUT selector
USB 1
OS
Windows
®
7 (32 bits/64 bits)/
Windows Vista
®
(32/64 bits)/
Windows
®
XP (32/64 bits) SP3 or later
CPU
Intel
®
Pentium
®
4 processor 1.6 GHz or higher processor
RAM 512 MB or greater
HDD 60 MB or greater free hard drive space
Supported models
PC/AT compatible machine equipped with a USB port
compliant with the USB standard Rev2.0 HS (Intel
®
USB
host controller is recommended)
