37
En
You can hide the display of those inputs that are not used,
so that they are skipped when selecting an input. Change
any input from the following: L1(LINE1), L2(LINE2),
L3(LINE3), CX1(COAX1), CX2(COAX2), OPT,
AES(AES-EBU), USB, PNO(PHONO)
Operating with the remote controller
Operating on the integrated amplifier
Tip
The default setting is ON.
Note
The current input doesn’t appear as selectable. For example, if
the input is currently set to “LINE1”, “L1” won’t appear as
selectable.
The integrated amplifier will end the setup if there is no
operation for 8 seconds.
Skipping Unused Inputs
1
Press SETUP.
2
Press !/" repeatedly to select “SHOW”.
3
Press ENTER.
4
Press !/" repeatedly to select the input you want
to change.
5
Press #/$ to switch between ON and OFF.
` ON:
Shows the display of selected input.
` OFF:
Hides the display of selected input.
The setting is automatically confirmed.
SETUP
!/"/#/$
ENTER
RETURN
6
Press RETURN repeatedly to exit the setup.
1
Press SETUP repeatedly to select “SHOW”.
2
Use the INPUT selector to select the input you want
to change.
3
Press and hold down SETUP.
The setting is switched ON/OFF.
The setting is automatically confirmed.
4
Press SETUP repeatedly to exit the setup.
SETUP
INPUT selector
You can set the volume when using headphones.
Operating with the remote controller
Setting the Headphone Level
1
Press SETUP.
2
Press !/" repeatedly to select “HPLVL”.
3
Press ENTER.
The current level is displayed.
4
Press #/$ repeatedly to adjust theoffset level.
You can adjust the offset level from -12 dB to +12 dB
in 1 dB steps.
The setting is automatically confirmed.
5
Press RETURN repeatedly to exit the setup.
SETUP
!/"/#/$
ENTER
RETURN
