Optex Virtual Loop - Dimensions; Options

-38-
10-3
Dimensions
10-4
Options
●Vertical Angle Adjustment Plate (3 °)
Up to three can be stacked in use.
● OVS-MP
for curb
for ground
Mini post for OVS series (US only)
OVS-MPB:Black
OVS-MPY:Yellow
OVS-MPBCURB:Black for curb
OVS-MPYCURB:Yellow for curb
[Unit: mm (in.)]
: Screw holes compatible
with OVS-01
78 (3 5/64)
170 (6 11/16)
80 (3 5/32)
Installation pitch
84.5 (3 11/32)
±1.5 (±1/16)
