OPTICON Universal menu book
U124
6.1. Buzzer settings
These options determine the buzzer type, tone,
duration and loudness. The buzzer tone and
loudness are reader dependent due to different
buzzer types.
Buzzer type:
The buzzer may be disabled or enabled as
either a hardware or software buzzer. Not all
readers support both a hardware and software
buzzer.
Buzzer tone:
If a software buzzer is used, the buzzer tone
may be selected as shown in figure 6.01.
Buzzer duration and loudness:
If a software buzzer is used, a buzzer duration
of 50, 100, 200 or 400 msec. may be selected.
The loudness can be adjusted in four different
steps.
Buzzer before transmission:
The good read buzzer will be activated after
decoding the bar code, but before transmission.
During the transmission the buzzer sequence
will be completed.
Buzzer after transmission:
The good read buzzer will be activated after
transmission.
Enable startup buzzer:
When this options is selected, the reader will
generate a single good read buzzer to indicate
the reader is ready after the reader is supplied
with power.
Disable startup buzzer:
When this options is selected, the reader will
not sound the buzzer after the reader is
supplied with power.
Frequency
3 KHz
3 KHz - 2.5 KHz
3 KHz - 4 KHz
Buzzer
Single tone
High - low
Low - high
Fig. 6.01. Buzzer Settings
Duration
100%
50% - 50%
50% - 50%
SET
_ZZ_
Disable buzzer
W0
_W0_
Enable buzzer
W8
_W8_
Single tone buzzer
W1
_W1_
High - low buzzer
W2
_W2_
END
_ZZ_
