Opticon UNIVERSAL MENU BOOK User Manual

Interface
2
OPTICON Universal menu book
U29
2.3.7. Wireless power saving
Activation levels:
In order to reduce the power consumption it is
possible to set the activity rate of the reader.
The default setting is ‘Active’, meaning that the
reader will continuously check for
communication. By setting the level to a certain
time the reader will reduce activity and check
for communication only at the set time.
Auto disconnect:
Power consumption can also be reduced by
auto disconnect settings as described in the
chapters: Auto disconnect options and Auto
reconnect options.
IEEE 802.15.4 power saving:
IEEE 802.15.4 based readers change the
antenna output power instead of changing the
activity rate. See figure 2.08.
Fig. 2.08. Power saving table
Power
level
Output
power
level 0
level 1
level 2
level 3
level 4
level 5
-3 dBm
-5 dBm
-7 dBm
-10 dBm
-15 dBm
-25 dBm
SET
_ZZ_
Level 0
LV00
_LV00_
Level 1 300 slots,
187.5ms
LV01
_LV01_
Level 2 500 slots,
312.5ms
LV02
_LV02_
Level 3 700 slots,
437.0ms
LV03
_LV03_
Level 4 900 slots,
562.5ms
LV04
_LV04_
Level 5 1100 slots,
687.5ms
LV05
_LV05_
Level 6 1300 slots,
812.5ms
LV06
_LV06_
Level 7 1500 slots,
937.5ms
LV07
_LV07_
END
_ZZ_
