U74
3.3.18. Options for Composite Codes
CC-A is a modified MicroPDF417 version.
CC-B is standard MicroPDF417.
CC-C is standard PDF417.
Maximum data capacity:
• CC-A: 56 characters
• CC-B: 338 characters
• CC-C: 2361 characters
Symbol size:
• 1D part: see RSS and EAN codes
• Composite part: CC-A and CC-B same as
MicroPDF417, CC-C same as PDF417
Error correction:
• 1D part: only error detection
• Composite part: Reed Solomon error
correction
Encodable characters:
• ASCII values 0 - 127 ( ISO 646 )
• ASCII values 128 - 255 ( ISO 8859-1, Latin
alphabet No. 1, extended ASCII )
• with ECI: many other character sets
For string format of composite codes see figure
3.41 or 3.42 or 3.43.
Options for Composite codes:
• enable composite code
• ignore link flag
• output mode
For string format of composite codes see figure
3.44.
Fig. 3.41. Options for Composite Codes
1D data
(1 upto 73 characters)
Composite A
composite data
(1 upto 56 characters)
Fig. 3.42. Options for Composite Codes
1D data
(1 upto 73 characters)
Composite B
composite data
(1 upto 338 characters)
Fig. 3.43. Options for Composite Codes
1D data
(1 upto 73 characters)
Composite C
composite data
(1 upto 2361 characters)
Fig. 3.44. Combined options
for Composite Codes
BHE
BHE
BHE
BHE
BHE
BHE
BHF
BHF
BHF
BHF
BHF
BHF
Composite
Enable
Output
Result
Link
Flag
Output
Mode
RP
RP
RP
RQ
RQ
RQ
RP
RP
RP
RQ
RQ
RQ
BL0
BL1
BL2
BL0
BL1
BL2
BL0
BL1
BL2
BL0
BL1
BL2
1D / 1D+2D
2D / 1D+2D
1D / 2D / 1D+2D
1D+2D
1D+2D
1D+2D
1D
2D
1D / 2D
1D
2D
1D / 2D
Fig. 3.44. Combined options
for Composite Codes
BHE
BHE
BHE
BHE
BHE
BHE
BHF
BHF
BHF
BHF
BHF
BHF
Composite
Enable
Output
Result
Link
Flag
Output
Mode
RP
RP
RP
RQ
RQ
RQ
RP
RP
RP
RQ
RQ
RQ
BL0
BL1
BL2
BL0
BL1
BL2
BL0
BL1
BL2
BL0
BL1
BL2
1D / 1D+2D
2D / 1D+2D
1D / 2D / 1D+2D
1D+2D
1D+2D
1D+2D
1D
2D
1D / 2D
1D
2D
1D / 2D
