Code options
3
OPTICON Universal menu book
U77
Options for DataMatrix:
• Structured append time out: see chapter
Read options
3.3.21. Options for Aztec
Aztec code is a variable size matrix symbology
with selectable error correction levels.
Maximum data capacity:
Standard Aztec:
• alphanumeric: 3067 characters
• numeric: 3832 characters
• byte: 1914 characters
Aztec runes:
• values 000 up to 255 ( 3 digits )
Symbol size:
Standard Aztec:
• minimum: 15 * 15 modules
• maximum: 151 * 151 modules
Aztec runes:
• fixed: 11 * 11 modules
Error correction:
User selectable Reed-Solomon error correction
levels from 5% to 95% of data region.
Additional features:
• extended Channel Interpretation (ECI):
support for different character sets and data
interpretations
• structured append: represent data in up to 26
Aztec symbols
• mirror image: decode symbol in mirror
reversal presentation
Support for these options is reader dependent.
The supported character set and the maximum
decodable number of characters, is reader dependent
Encodable characters:
• ASCII values 0 - 127 ( ISO 646 )
• ASCII values 128 - 255 ( ISO 8859-1, Latin
alphabet No. 1, extended ASCII )
• with ECI: many other character sets
For string format see figure 3.47.
Options for Aztec:
• structured append time out: see chapter
Read options
Fig. 3.46. Options for DataMatrix
data
(1 upto 3116 characters)
DataMatrix
Fig. 3.47. Options for Aztec
data
(1 upto 3832 characters)
Aztec
