Opticon UNIVERSAL MENU BOOK User Manual

OPTICON Universal menu book
U88
Fig. 4.07. Modifiers for Codabar
Codabar normal mode (HA)
Not check CD (H7)
Transmit CD (H8)
Codabar ABC (H3 or H4)
Not check CD (H7)
Transmit CD (H8)
Codabar normal mode (HA)
Check CD (H6)
Transmit CD (H8)
Codabar ABC (H3 or H4)
Check CD (H6)
Transmit CD (H8)
Codabar normal mode (HA)
Not check CD (H7)
Not transmit CD (H9)
Codabar ABC (H3 or H4)
Not check CD (H7)
Not transmit CD (H9)
Codabar normal mode (HA)
Check CD (H6)
Not transmit CD (H9)
Codabar ABC (H3 or H4)
Check CD (H6)
Not transmit CD (H9)
]F0
]F1
]F2
]F3
]F4
]F5
]F6
]F7
AIM/ISO15424 Code identifiers for : F*
Code options
]AIM-ID
Fig. 4.08. Modifiers for Interleaved 2of5
Not check CD (G0)
Check CD (G1)
Not check CD (G0)
Check CD (G1)
]I0
]I1
]I2
]I3
AIM/ISO15424 Code identifiers for : I*
Code options
]AIM-ID
Transmit CD (E0)
Transmit CD (E0)
Not transmit CD (E1)
Not transmit CD (E1)
Fig. 4.09. Modifiers for IATA
Not check CD (4H)
Transmit CD (4L)
Check FC and SN only (4I)
or Check CPN,FC and SN (4J)
or Check CPN,AC,FC and SN (4K)
Transmit CD (4L)
Not check CD (4H)
Not transmit CD (4M)
Check FC and SN only (4I)
or Check CPN,FC and SN (4J)
or Check CPN,AC,FC and SN (4K)
Not transmit CD (4M)
]R0
]R1
]R2
]R3
AIM/ISO15424 Code identifiers for : R*
Code options
]AIM-ID
Fig. 4.10. Modifiers for MSI/Plessey
]M0
]M1
]X0
]X0
]X0
]X0
AIM/ISO15424 Code identifiers for : M* / X0
Code options Checksum
+ Transmit
]AIM-ID
Check 1 CD = MOD 10 (4B):
(4B)
+ Transmit CD1
(4B)
+ Not transmit CD
(4B)
+ Transmit CD1 and CD2
Check 2 CD's = MOD 10/ MOD 10 (4C):
(4C)
+ (4E) or (4G) or (4F)
Check 2 CD's = MOD 10/ MOD 11 (4D):
(4D)
+ (4E) or (4G) or (4F)
Check 2 CD's = MOD 11/ MOD 10 (4R):
(4R)
+ (4E) or (4G) or (4F)
(4E)
(4G)
(4F)
Fig. 4.11. Modifiers for Telepen
AIM/ISO15424 Code identifiers for : B*
Code options
]AIM-ID
]B0
]B1
]B0
]B2
]B0
]B2
Telepen (numeric or ASCII only):
ASCII mode (D3)
Numeric mode (D2)
Telepen (numeric followed by ASCII):
ASCII mode (D3)
Numeric mode (D2)
Telepen (ASCII followed by numeric)(not supported):
ASCII mode (D3)
Numeric mode (D2)
