Appendix
OPTICON Universal menu book
U131
A. TROUBLE SHOOTING
The trouble shooting diagram can be of help if
your reader does not operate as expected. If
any problem is not covered or solved with this
diagram you need to contact your dealer.
Whether the reader operates or not can be
checked in the following way:
• it should beep after the power has been
switched ON
• it should either react on a trigger(if any) or it
should emit light at the scan side of the
reader (LEDs)
See figure A.01.
Check
cabling
Reader
operates?
Problems
reading menu?
Reads
bar codes?
Garbage
on screen?
Reads any
label?
Software and menu do not match.
Use matching menubook
Scans
SET/END?
Setup reader or
contact dealer
Setup bar code
options
Setup
reader interface
Reader defect
contact dealer
Low buzzer indicates
unsupported option
No
No
No
No
NoNo
Yes Yes
Yes
Yes
Yes
Yes
Fig. A.01. Trouble shooting
