String options
4
OPTICON Universal menu book
U89
Fig. 4.12. Modifiers for Code 11
AIM/ISO15424 Code identifiers for : H* / X0
Code options
]AIM-ID
Check 1 CD (BLG)
or Check auto 1 or 2 CDs (BLI)
(length < 12)
Transmit CD(s) (BLK)
Check 2 CDs (BLH)
or Check auto 1 or 2 CDs (BLI)
(length > 12)
Transmit CD(s) (BLK)
Check 1 CD (BLG)
or Check 2 CDs (BLH)
or Check auto 1 or 2 CDs (BLI)
(length > 12)
Not transmit CD(s) (BLJ)
Not check CD (BLF)
Not transmit CD(s) (BLJ)
]H0
]H1
]H3
]X0
Fig. 4.13. Modifiers for Codablock F
AIM/ISO15424 Code identifiers for : O*
Data structure
]AIM-ID
]O4
]O5
FNC1 not used
FNC1 in 1st position
Fig. 4.14. Modifiers for DataMatrix
AIM/ISO15424 Code identifiers for : d*
Symbology, data structure
]AIM-ID
]d0
]d1
]d2
]d3
]d4
]d5
]d6
ECC000 - ECC140
ECC200
ECC200, FNC1 in 1st or 5th position
ECC200, FNC1 in 2nd or 6th position
ECC200, supporting ECI protocol
ECC200, FNC1 in 1st or 5th position and
supporting ECI protocol
ECC200, FNC1 in 2nd or 6th position and
supporting ECI protocol
Fig. 4.15. Modifiers for Aztec
AIM/ISO15424 Code identifiers for : z*
Data structure
]AIM-ID
]z0
]z1
]z2
]z3
]z4
]z5
]z6
]z7
]z8
]z9
]zA
]zB
]zC
No structure / other
FNC1 preceeding 1st message character
FNC1 following an initial letter or pair of digits
ECI protocol implemented
FNC1 preceeding 1st message character and
ECI protocol implemented
FNC1 following an initial letter or pair of digits,
ECI protocol implemented
Structured append header included
Structured append header included and
FNC1 preceeding 1st message character
Structured append header included,
FNC1 following an initial letter or pair of digits
Structured append header included and
ECI protocol implemented
Structured append header included,
FNC1 preceeding 1st message character,
ECI protocol implemented
Structured append header included,
FNC1 following an initial letter or pair of digits,
ECI protocol implemented
Aztec runes
Fig. 4.16. Modifiers for QR Code
AIM/ISO15424 Code identifiers for : Q*
Model, data structure
]AIM-ID
]Q0
]Q1
]Q2
]Q3
]Q4
]Q5
]Q6
Model 1
Model 2, ECI protocol not implemented
Model 2, ECI protocol implemented
Model 2, ECI protocol not implemented,
FNC1 in first position
Model 2, ECI protocol implemented,
FNC1 in first position
Model 2, ECI protocol not implemented,
FNC1 in second position
Model 2, ECI protocol implemented,
FNC1 in second position
Fig. 4.17. Modifiers for Maxicode
AIM/ISO15424 Code identifiers for : U*
Data structure
]AIM-ID
]U0
]U1
]U2
]U3
Symbol in mode 4 or 5
Symbol in mode 2 or 3
Symbol in mode 4 or 5,
ECI protocol implemented
Symbol in mode 2 or 3,
ECI protocol implemented
