optris LS – E2006-01-A
30
O
PENING OF
F
ILES
To open a saved file please press the button Open [Menu: File\ Open]. You can select the desired file in the
newly opened explorer window [file type: *.dat].
The data files can also be opened and edited with any text editor or with Microsoft Excel.
D
IAGRAM
S
ETTINGS
The menu item Settings [Menu: Diagram\ Settings] enables the selection of the following diagram options:
Digital Selection which signals should be displayed
as digital display
Diagram Selection which signals should be displayed
as graph [TObj, TInt, TExt]
Pen Width Pen width of the temperature graphs [1...5]
Color Color of the temperature graph and digital
displays
Initial time Time frame on the x-axis, which should be
displayed at the beginning of a measurement
