Oracle Database Appliance User Manual

Replace a Storage Shelf HDD or SSD
Chapter3 • Servicing CRUs That Do Not Require System Power Off 41
■
“Replace a Storage Shelf HDD or SSD” on page 41
■
“Replace a Storage Shelf Power Supply” on page 43
■
“Replace a Storage Shelf I/O Module” on page 45
Replace a Storage Shelf HDD or SSD
1.
Locate the failed drive on the front of the chassis.
Caution - Equipment damage. Do not remove a drive unless you have an immediate
replacement.
2.
Press the latch to release the drive lever.
3.
Pull the drive lever to the open position.
4.
Grasp the middle of the drive body and pull it toward you to remove it from the
chassis.
Example showing the DE2-24P:

Oracle Database Appliance Specifications

General

Product Type	Database Appliance
Form Factor	Rack-mountable
Storage Type	SSD
RAID Support	RAID 1, RAID 5, RAID 6, RAID 10
Storage Expansion	Yes
Maximum Disk Drives	Varies by model (e.g., 12, 18, 36)
