Oracle Server X6-2 User Manual

Install Mounting Brackets Onto the Server
Install Mounting Brackets Onto the Server
To install the mounting brackets onto the sides of the server:
1.
Position a mounting bracket against the chassis so that the slide-rail lock is
at the server front, and the five keyhole openings on the mounting bracket are
aligned with the five locating pins on the side of the chassis.
Callout Description
1 Chassis front
2 Slide-rail lock
3 Mounting bracket
4 Mounting bracket clip
2.
When the heads of the five chassis locating pins protrude through the five
keyhole openings in the mounting bracket, pull the mounting bracket toward
42 Oracle Server X6-2 Installation Guide • July 2020
