Connect Cables and Power Cords
■
Remote sideband management connnection – For information, refer to Sideband Network
Management Connection in the Oracle ILOM Administrator's Guide for Configuration and
Maintenance, Firmware Release 3.2.x at https://www.oracle.com/goto/ilom/docs.
■
Host-to-Ilom interconnect – For information, refer to Dedicated Interconnect SP
Management in the Oracle ILOM Administrator's Guide for Configuration and
Maintenance, Firmware Release 3.2.x at https://www.oracle.com/goto/ilom/docs
Caution - Do not apply full main power to the server until instructed to do so. To properly
configure the server and to view SP messages, cable the server as described in this procedure
before applying power to the server.
Connect Cables and Power Cords
Refer to Figure 1, “Rear Panel Cabling Reference,” on page 72 to locate the ports and AC
inlets on the server back panel.
1.
Connect a serial cable between the server's serial management port (SER MGT)
and a terminal device.
This connection provides the initial communication to the SP.
2.
(Optional) Connect an Ethernet cable between the network management port
(NET MGT) and the network to which connections to the Oracle ILOM SP and
host will be made.
Configure the server for the first time using the SER MGT port. After initial configuration, you
can set up communication between the SP and host through this Ethernet interface.
3.
For network access, connect an Ethernet cable between one of the the
server's Ethernet NET ports (NET0-3) and the network to which the server will
communicate.
Note - Ethernet ports NET2 and NET3 are non-functional in single-processor systems.
4.
Connect the power cords to the two AC inlets on the back panel of the server.
