OTARI MX-5050 - Chassis Assembly (BIII)

Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 4
Chassis Assembly: T0067
No. Description Parts No. Notes
1 Panel, Deck Cover T006702
2 Blind T006703
3 Control Assembly CB-23U
4 Panel, Top T006701
5 Transformer, Power TF11030
6 Frame T006708
7 Angle T506405
8 Bracket L T007104
9 Bracket R T007105
10 Bracket T006705
11 Cover, Fuse T005306
12 FUSE PCB Assembly PB-7VCA
13 Bracket L T006710
14 Bracket R T006709
15 CONTROL PCB Assembly PB-4RNA
16 Angle, Frame T506104
17 Washer, Trim KZ6C051
18 Washer KZ6C011
19 Stud KZ9L080A
20 Stud KZ9A095B
