Section 4 Operation
4 - 4
May 1992
MX-5050 Operation and Maintenance Manual
4.2.2 Audio Channel Modes
❏ Record Ready mode: When the RECORD and PLAY buttons are pressed, any
channel which is in Record Ready will begin to Record. To place a channel
into Record Ready mode, press the RECORD mode button for that channel.
The Record mode indicator will illuminate and the indicator on the RECORD
button will flash.
❏ Record Safe mode: In Record Safe mode, Record mode cannot be entered.
To place a channel in Record Ready mode into Record Safe mode, press the
RECORD mode button for that channel to the SAFE postion (not depressed).
The Record mode indicator(s) will extinguish. When the Record mode
indicator is extinguished, that channel is in Record Safe mode.
❏ Input Monitor mode: In Input Monitor mode, the signal at the OUTPUT
connectors, VU Meters, PHONES connector, and Monitor Speaker is the
signal present at the INPUT connector for that channel. To place a channel
into Input Monitor mode, set the Monitor button for that channel to SOURCE
position (not depressed).
❏ Sel-Rep Monitor mode: In Sel·Rep (Selective Reproduce) Monitor mode, the
signal at the OUTPUT connectors, VU Meters, PHONES connector, and
Monitor Speaker is the signal on tape reproduced by the Record Head for that
channel. To place a channel into Sel·Rep Monitor mode, press the SEL·REP
Monitor button for that channel.
