Section 2 Installation
2 - 2
May 1992
MX-5050 Operation and Maintenance Manual
2.1 Unpacking and Inspection
After receiving the MX-5050, examine the case for any signs of damage.
Then unpack and inspect the equipment. Take care when unpacking the
equipment and removing packing materials to prevent damaging the critical
components such as the capstan, head assembly, and tension arms. If there
is any evidence of damage due to rough handling during transportation, a
claim should be filed with the transportation company. We recommend
retaining the packing material at least until proper operation of the machine
has been established.
Verify that all items, as listed in Table 2-1, have been received. Do not
connect or operate the MX-5050 until this inspection has been completed.
When sending the machine back to the local OTARI dealer or to OTARI, follow
the packing directions printed on the carton.
Table 2-1
Standard Accessories
MX-5050 B
III, MKIV-2
Parts Name Part No. Quantity
Reel Clamp KW0HV 2
Power Cable PZ9D003 1
Manual OS3-298 1
Lubrication Oil PZ9E003 1
Fuse 1A FH7F010 1
(Fuse 1A 200-240V only FH9-032 1)
Fuse 2A FH9-030 1
Fuse 2A FH7F020 1
Fuse 3A FH7F030 1
Fuse 4A FH7F040 1
Fuse 5A FH7F050 1
