OTARI MX-5050 - MX-5050 Mkiv2

MX-5050 Operation and Maintenance Manual
May 1992
Section 2 Installation
2 - 11
2.4.2 MX-5050 MKIV2
The AMP section of the MKIV-2 is adjusted after removing the Top Panel.
❏ Accessing the AMP Section
1. Turn off the machine. Remove the Top Panel (for MKIV-2).
2. Adjust the PCB Assemblies (REC/REP AMP PCB Assembly) located inside the
AMP section.
CONTROL PCB
SCREW
REC/REP PCB
REC/REP PCB
CONTROL PCB
Figure 2-8
PCB Assembly Location
