OTARI MX-5050 - Electronics Specifications

MX-5050 Operation and Maintenance Manual
May 1992
Section 8 Specifications
8 - 3
8.2 Electronics
Input Line Mode: Transformerless Active Balanced
Input Impedance: 100kΩ, 20Hz–20kHz
Nominal Level: +4dBu
Max. Level: +30dBu
Connectors: XLR Female type
Mic Mode: Transformerless Active Balanced
Input Impedance: 10kΩ
Min. Level: –70dBu/–50dBu/OFF switchable
Mic. Impedance: Min. 150Ω
Output Line Mode: Transformerless Active Balanced
Output Impedance: Max 5Ω (20Hz–20kHz)
Load Impedance: MIn. 200Ω
Nominal Level: +4dBu/–16dBu switchable
Max Level: +26dBu for 200Ω
Connectors: XLR Male type
Phone Load Impedance: 8Ω
1/4" Standard Stereo Phone Jack
Note: 0dBu = 0.775V
Equalization NAB/IEC Selectable
Standard Reference Flux MX-5050 BIII-2, MKIV-2, BIII-F 185/250/320* nWb/m
MX-5050 BIII-2E, MKIV-2E 250/320/510* nWb/m
(*open circuit flux)
Frequency Response
REC/REP Frequency Response
15 ips 30Hz - 20kHz ±2dB
7.5 ips 30Hz - 18kHz ±2dB
3.75 ips 20Hz - 10kHz ±2dB
REC/SEL-REP Frequency Response
15 ips 250Hz - 7.5kHz ±3dB
7.5 ips 250Hz - 5kHz ±3dB
3.75 ips 250Hz - 2.5kHz ±3dB
Signal to Noise Ratio
Measured with respect to a recording level of 1,040 nWb/mat 15 and 7.5 ips,
and 740 nWb/m at 3.75 ips, using AMPEX 456 or equivalent tape.
Unwtd: Using a 30Hz to 18kHz RC filter to eliminate noise outside the audio
spectrum.
Wtd: Using a NAB or ANSI "A" weighting filter and a 1kHz reference.
Model BIII-2, MKIV-2, 2E
BIII-F
Track (2mm) Track (2.75mm)
Unwtd Wtd Unwtd Wtd Unwtd Wtd
Filter
Speed EQ
15ips
NAB
7.5ips
NAB
3.75ips
NAB
70
69
67
71
64
64
73
72
70
73
67
67
71
70
68
72
65
65
74
73
71
74
68
68
74
73
71
75
68
68
77
76
74
75
71
71
IEC
IEC
IEC
