OTARI MX-5050 - Case Assembly (BIII)

Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 2
BIII Case Assembly: K1168
No. Description Parts No. Notes
1 Rear Cover Assembly K1168-A
2 Grille, Ventilation CY5001A
3 Plate C K102911
4 Foot CY4013
5 Panel, Side K116802
6 Hundle CY1004
7 Washer, Trim KZ6C028
8 Connector Panel Assembly CB792
9 Panel, Rear A106204
10 Plate, L K102909
11 Plate, R K102910
12 Grille, Ventilation CY5001A
13 Plate K102907
14 Panel, Bottom K102906A
15 Foot, Case CY4011-A
