Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 6
Head Assembly: KH-44K
No. Description Parts No. Notes
1 Head Housing Assembly KH-4Y-A
2 Stud KH4Y009
3 Base, Head KH0C047
4 Spring, Head Adjustment GS2016
5 Bracket, Head KH0D178
6 Post, Guide KG4E001 Head Sub Assembly
7 Erase Head Assembly, KH-44KA
1/4" 2CH GH4E082B
8 Record Head Assembly,
1/4" 2CH GH4R005B
9 Reproduce Head Assembly,
1/4" 2CH GH4P027B
10 Cover, Housing KH0F038
11 Head Housing,Front KH0F037
12 Guide, Tape KG4A003
13 Connector CN314002
14 Bracket, Connector KH4Y004
15 Plate, Shield KH4Y001A
16 Pole, Guide KG6E020
17 Clamp, Cable PZ1G053
18 Bracket L, PCB KH41I01
19 Bracket R, PCB KH41I02 Head Sub Assembly
20 Cover, Protection KH41T02 KH-44KA
21 HEAD, RELAY PCB Assembly PB-78IAB
22 Washer, Polyslider F523030
To Next Page
