OTARI MX-5050 - Reel Assembly (BIII)

Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 8
Reel Assembly : KW-41J
No. Description Parts No. Notes
1 Reel Shaft Assembly KW-41DG
2 Reel Table Assembly KW-41EA
3 Holder, Reel Table KW0B056
4 Protector, Reel KW0H007A
5 Bracket, Reel Motor KW0G016
6 Motor, Reel MR1C005
7 Base L , Brake KW0G013
8 Bracket, Connector KW41J01
9 Base R, Brake KW0G012
10 Brake Band Assembly KW-4J-A
11 Spring GS1175
12 Stopper, Cable KZ3A047
13 Pin, Solenoid KZ5A003
14 Solenoid GP1F03
15 Damper PZ1B049
16 Guide, Brake KW4B001
17 Drum, Brake KW0A012
18 Ring, E type F74TE15
19 Ring, E type F74TE09
20 REEL MOTOR DRIVE PCB Assembly PB-4RNA
21 Bracket A, Reel Motor Draive PCB T005317
22 Bracket B, Reel Motor Draive PCB T005318
