OTARI MX-5050 - Control Assembly (BIII)

Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 14
Control Assembly: CB-23U
No. Description Parts No. Notes
1 Panel, Control CB23U01
2 Sheet, Control Panel CB23U02
3 Switch, Power WH42062
4 Capacitor, Spark Killer CZ20001W
5 TRANSPORT CONTROL SWITCH
PCB Assembly PB-7UZA
A Button, CUE KN2145
B Button, EDIT KN2147
C Button,RECORD KN2144
D Button, PLAY KN2142 Assembly
E Button, STOP KN2141
F Button, F.FWD , RWD KN2143
G Switch, Selector KN2184
H Knob KN1108
H Cap, Knob KN1099
6 Escutcheon, Switch PZ4A026
7 Escutcheon, Switch PZ4A027
8 Angle T006704
9 Stud KZ7B160
10 Stud KZ7B158
11 Stud KZ7B159
12 Connector Housing, Plug CN402029
13 Connector Contact, Plug CN7B-041
14 Connector Housing, Receptacle CN402030
15 Connector Contact, Receptacle CN7B-042
