OTARI MX-5050 - Amplifier Assembly (BIII)

Section 9 and Exploded Views and Parts List
December 1997
MX-5050 Operation and Maintenace Manual
9 - 16
Amplifier Assembly: A1220
No. Description Parts No. Notes
1 Cap, Knob KN1102
2 Knob KN1100A
3 Collar KZ7C111
4 Knob KZ1063B
5 Spacer KZ6C017
6 Potentiometer RV224005
7 Amp Trim Panel Assembly A1220-A
8 Panel, Amp. Top A1220-B
9 VU Meter ME11005
10 Jack, Phone CN602144
11 Switch WH340013
12 Button KN2095
13 Button KN2094
14 Button KN2093
15 Blind PZ1B012
16 Blind PZ1B010
17 Frame L, Amp A102808
18 Frame R, Amp A102807
19 Bracket, PCB A106206
20 Collar A102809
21 Shield, Illumination PZ1B013
22 REC/REP AMP PCB Assembly PB-1GYA (BIII-2)
PB-16EJ (BIII-F)
PB-1GYC (BII-2E)
23 LED PCB Assembly PB-83AB
24 LED PCB Assembly PB-83BB
25 LED PCB Assembly PB-83CAA
26 LED PCB Assembly PB-81JB
27 REC EQ PCB Assembly PB-81QA
28 VU Meter Amp. PCB Assembly PB-16DB
29 Washer, Trim KZ6C051
30 Washer KZ6C011
31 Spacer A122004
