OTARI MX-5050 - Case Assembly (MKIV-2)

Section 9 and Exploded Views and Parts List
December 1997
MX-5050 Operation and Maintenace Manual
9 - 20
MKIV-2 Case Assembly: K1170
No. Description Parts No. Notes
1 Tape Deck Assembly T0069
2 Head Assembly KH-44K
3 Audio Amplifier Assembl A1221
4 Cover, Front K117001
5 Cover, Front K117002
6 Cover, Under K117003
7 Panel A, Side K117201
8 Panel B, Side K117202
9 Cover, Ventilation K117205
10 Frame R K117007
10' Frame L K117006
11 Panel, Rear K117005
12 Connector Panel Assembly CB-794
13 Bracket R, Chassis K117210
13' Bracket L, Chassis K117211
14 Frame, Under K117209
15 Cover, Under K117212
16 Foot CY4058
17 Washer, Trim KZ6C028
18 Washer, Trim KZ6C051
19 Washer KZ6C011
20 Stud KZ9L150A
