OTARI MX-5050 - Chassis Assembly (MKIV-2)

Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 22
Chassis Assembly: T0069
No. Description Parts No. Notes
1 Panel, Deck Cover T006711
2 Blind T006703
3 Control Assembly CB-23U
4 Angle T007107
5 Panel, Deck T006701
6 Transformer, Power TF11030
7 Frame T007101
8 Angle T506405
9 Bracket L T007104
10 Bracket R T007105
11 Bracket L T007102
12 Bracket R T007103
13 Bracket T006705
14 Cover, Fuse T005306
15 FUSE PCB Assembly PB-7VCA
16 CONTROL PCB Assembly PB-4RMA
17 Washer, Trim KZ6C051
18 Washer KZ6C011
19 Bracket L T006710
20 Collar, Screw KZ7C091
21 Stud KZ9L080A
