OTARI MX-5050 - Pinch Roller;Capstan;Shifter Assembly (MKIV-2)

Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 28
Pinch Roller Assembly: KP-4X
Capstan Assembly: KC-41H
Shifter Assembly: KR-4W
No. Description Parts No. Notes
1 Cap. Pinch Roller KP0C034
2 Pinch Roller Assembly KP-4S-B
3 Shaft, Pinch Roller KP0B060
4 Shaft, Arm KP4L001
5 PinchRoller Arm Assembly KP-4X-A
6 Solenoid GP1B12
7 Screw, Adjustment KZ6A113
8 Damper PZ1C021
9 Washer Spherical KP0G004
10 Spring GS2163
11 Nut, Dubble F517-4
12 Pin, Solenoid KZ5A003
13 Stopper, Solenoid KZ2A016
14 Stud KZ9I250A
15 Bracket, Motor KC4H001
16 Cap, Dust KC0B029
17 Ring PZ1C130
18 Motor, Capstan MR-1L
19 Shaft, Link Arm KR4W005
20 Shifter Link Assembly KR-4W-A
21 Collar KZ7C109
22 Shaft, Arm KR4B001
23 Arm A, Lifter KR0B005
24 Arm B, Lifter KR0B006
25 Bracket, Shifter Solenoid KR4W007
26 Solenoid GP1A09
27 Arm, Link KR4W004
28 Angle KZ3A042
29 Pipe, Rubber PZ1C174
30 Hook KZ3A167
31 Spring GS1185
32 Spring GS1028-A
33 Spring GS1149
34 Washer, Polyslider F524060
35 Stud KZ7A823
36 Ring, E type F74TE09
37 Ring, E type F74TE20
38 Ring, E type F74TE15
