Section 9 and Exploded Views and Parts List
May 1992
MX-5050 Operation and Maintenace Manual
9 - 30
Tension Arm Assembly: KA-4X/KA-4Y
Impedance Roller Assembly: KI-4T
Timer Assembly: ZA-95G
No. Description Parts No. Notes
1 Cap, Arm KA0C005
2 Arm, Tension KA0A017A
3 Shaft, Arm KA4J001
4 Washer, Polyslider F524-5
5 Holder, Arm KA0B008
6 Guide, Tape KG4D007
7 Hook, Spring KZ3A024
8 Nut KZ6D004
9 Hook A, Spring KA0E017
10 Arm, Stopper KA4X001
11 Hook B, Spring KA0E005
12 Switch Actuator Assembly KA-4K-B
13 Magnet Assembly KA-4K-C
14 Roller Assembly KI-4J-B
15 Collar KZ7C057
16 Bearing BA1Z022
17 Ring F7017 Impedance Roller
18 Holder KI0B014 Sub Assembly
19 Spring GS2077 KI-4J-A
20 Washer KZ6C057
21 Ring, Shaft F7206
22 Washer KI0H024
23 Nut, Holder KI0H025
24 Boss KI4T001
25 Disk, Tacho SR3Z033
26 Stud KZ9H480C
27 ROLLER TACHO PCB Assembly PB-4HCA
28 Timer Display Assembly ZA-95G
29 Spring GS1025
30 Spring GS1048
31 Switch, Micro WH51027
32 Hook, Spring KZ3A023
33 Hook KZ3A167
34 Bracket KZ2A165
