Section 9 and Exploded Views and Parts List
December 1997
MX-5050 Operation and Maintenace Manual
9 - 34
Amplifier Assembly: A1221
No. Description Parts No. Notes
1 Cap, Knob KN1102
2 Knob KN1100A
3 Collar KZ7C111
4 Knob KZ1063B
5 Spacer KZ6C017
6 Potentiometer RV224005
7 Amp. Trim Panel Assembly A1220-A
8 Panel, Amp. Top A1220-B
9 VU Meter ME11005
10 Jack, Phone CN602144
11 Switch WH340013
12 Button KN2095
13 Button KN2094
14 Button KN2093
15 Blind PZ1B012
16 Blind PZ1B010
17 Amp. Side L Assembly A1177-C
18 Amp. Side R Assembly A1177-B
19 Cover, Amp. A117705
20 Amp. Connector Panel Assembly A117701
21 Shield, Illumination PZ1B013
22 REC/REP AMP. PCB Assembly PB-1GYB
23 LED (D) PCB Assembly PB-83AB
24 LED (F) PCB Assembly PB-83BB
25 LED (E) PCB Assembly PB-83CAA
26 LED (C) PCB Assembly PB-81JB
27 REC EQ PCB Assembly PB-81QA
28 VU METER AMP. PCB Assembly PB-16DB
29 Washer, Trim KZ6C051
30 Washer KZ6C011
31 Spacer A122004
