MX-5050 Operation and Maintenance Manual
May 1992
Section 3 Controls and Indicators
3 - 13
Table 3-3
Remote Control Connector (MKIV-8 Option)
CH PIN CH PIN
CH1 1 - 14 CH5 5 - 18
CH2 2 - 15 CH6 6 - 19
CH3 3 - 16 CH7 7 - 20
CH4 4 - 17 CH8 8 - 21
