900-0054-01-00 Rev A 9
FLEXmax Charge Controller Disassembly
If you have a FLEXmax 60, proceed with removing t he chassis screws as described on page 10.
Removing the FLEXmax 80 Fan Cable
Figure 3 Removing Fan Cover
Figure 4 Removing Cable Jack
1. Remove the machine screw that secures the
fan cover.
2. Press bot h sides of the fan cover t o release t he
tabs. Pull up on the cover.
3. Remove the fan cover once the tabs have
cleared t heir slots. Keep t he fan cover and
machine screw in a safe place.
4. Note the fan cable plugged into the jack.
6. Not e t he jack for the fan
cable, which is snapped
int o t he fan bracket .
5.
Remove t he fan cable
by squeezing the tabs
on eit her side of t he
plug. You can do this
wit h your fingers, or
wit h a pair of long-
nose
liers.
Pr ess
7. Remove the cable jack by
pinching the retaining
tabs on either side of the
jack, using long-nose
pliers. The jack can be
taken out through the
rear of t he bracket .
Press
To Next Page
