Reassembly

900-0054-01-00 Rev A 31

For the FLEXmax 80 Controller, follow the steps on for reinstalling t he fan plug before proceeding.

Reinstalling FLEXmax 80 Fan Plug

Figure 47 Reinstalling Cable Jack

Fi g u r e 48 Rei n st al l i n g Cab l e Pl u g

Fi gur e 49 Fan Cover

Snap t he fan cable jack int o t he

bracket.

Snap t he fan cable int o t he jack.

Replace t he FLEXmax 80 fan cover.
