OutBack Power FLEXmax Series User Manual

Reassembly
30 900-0054-01-00 Rev A
Reconnecting the Heat Sink to the Chassis
Figure 45 Reinstalling the Heat Sink onto the Chassis
Figure 46 Repl aci ng t he Chassi s Scr ews
1. Slide the reassembled unit into
the chassis working around the
Grounding lug.
Grounding lug
2. Replace and tighten down
all
t he
screws on the back of the chassis.
3. Replace and tighten down
all
t he
screw s on t he si des of t he chassi s.
