Disassembly
900-0054-01-00 Rev A 13
Fi gur e 11 Fr eei n g t he FET f r om t h e Insul at or
Fi gur e 12 Fr eei ng t h e FET wi t h Pl i er s
3.
Lift t he t ab of t he FETs off
from the Sil-Pad (gray
insulator pad) using your
finger and thumb.
CAUTION! Do not at t empt
to remove the FETs from
the power board. The FET
pins are soldered t o t he
board.
If t he FETs are difficult to
break free, rock the tabs
gently with long-nose pliers
until they lift off the Sil-Pad.
