Ref.No. Part No. Part Name & Description Pc
Remarks Ref.No. Part No. Part Name & Description Pc
Remarks
P9 VJP2741A004 CONNECTOR (MALE) 1 K1KA04A00236
E1 VEP20816A CAM MOTHER P.C.BOARD 1 (RTL) P10 VJP4395D002 CONNECTOR (MALE) 1
P11 VJP4395D003 CONNECTOR (MALE) 1
E2 VEP23516A CAM DIGITAL P.C.BOARD 1 (RTL)FOR AJ-CA900HP P12 VJP4395D014 CONNECTOR (MALE) 1
E2 VEP23516B CAM DIGIATL P.C.BOARD 1 (RTL)FOR AJ-CA900HEN P13 VJP4395D015 CONNECTOR (MALE) 1
P14 VJP4395B006 CONNECTOR (MALE) 1
E3 VEP21250A CAM POWER P.C.BOARD 1 (RTL) P15 VJP4395D004 CONNECTOR (MALE) 1
P16 VJP4395D008 CONNECTOR (MALE) 1
E4 VEP24165A CAM ICOM P.C.BOARD 1 (RTL)
R1-R4 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 4
E5 VEP20817A CAM RET P.C.BOARD 1 (RTL)
TH1 D4ZZ00000018 THERMISOTR 1
E6 VEP20837A CAM IF P.C.BOARD 1 (RTL)
E7 VEP20835A CAM DCIN P.C.BOARD 1 (RTL)
E8 VEP27216A CAM RF ASS'Y 1 (RTL)
E2 VEP23516A CAM DIGITAL P.C.BOARD 1 (RTL)FOR AJ-CA900HP
E9 VEP20834A CAM FIL ASS'Y 1 (RTL) E2 VEP23516B CAM DIGIATL P.C.BOARD 1 (RTL)FOR AJ-CA900HEN
C1 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
C2 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C3 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
C4 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C6 ECUM1E224ZFN C.CAPACITOR CH 25V 0.22U 1
C7-10 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 4
C11 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
C12,13 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
C14,15 ECST1AY106 T.CAPACITOR CH 10V 10U 2
C16,17 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
C18 ECST1AY106 T.CAPACITOR CH 10V 10U 1
C19 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
E1 VEP20816A CAM MOTHER P.C.BOARD 1 (RTL) C20 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C21 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
C22 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
D1 S3V60 DIODE 1 B0EAKR000020 C24 ECUM1E224ZFN C.CAPACITOR CH 25V 0.22U 1
C25-28 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 4
J1 VEE0S43 CABLE 1 C29 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
C30,31 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L6 J0JKC0000009 FILTER 1 C32,33 ECST1AY106 T.CAPACITOR CH 10V 10U 2
L11 VLP0353 COIL 1 C34,35 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L12 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C36 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L13 VLP0353 COIL 1 C37 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L14 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C38,39 ECST1AY106 T.CAPACITOR CH 10V 10U 2
L15 VLP0353 COIL 1 C40 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L16 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C41 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L17-21 VLP0353 COIL 5 C42,43 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L22 J0JKC0000009 FILTER 1 C44 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
L23 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C45 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L24 VLP0353 COIL 1 C46 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
L25 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C48 ECUM1E224ZFN C.CAPACITOR CH 25V 0.22U 1
L26 VLP0353 COIL 1 C49-52 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 4
L27 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C53 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
L28 VLP0353 COIL 1 C54,55 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L29 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C56,57 ECST1AY106 T.CAPACITOR CH 10V 10U 2
L30-34 VLP0353 COIL 5 C58,59 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L35 J0JKC0000009 FILTER 1 C60,61 ECST1AY106 T.CAPACITOR CH 10V 10U 2
L36 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C62-67 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 6
L37-40 VLP0353 COIL 4 C68 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L41 J0JKC0000009 FILTER 1 C69 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L42 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C70 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L43,44 VLP0353 COIL 2 C71-73 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 3
L45 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C74 ECUX1H103KBV C.CAPACITOR CH 50V 0.1U 1 FOR VEP23516A
L46-49 VLP0353 COIL 4 C75 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
L50 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C76 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
L51 J0JKC0000009 FILTER 1 C77 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
L52 VLP0353 COIL 1 C78 ECUX1H471JCV C.CAPACITOR CH 50V 470P 1 FOR VEP23516B
L53 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C79 ECST0JC686 T.CAPACITOR CH6.3V 68U 1
C80 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
P1 VJS4064N070E CONNECTOR 1 C81 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
P2 VJP2824A002 CONNECTOR (MALE) 1 K1KA02A00009 C82 ECST1AY106 T.CAPACITOR CH 10V 10U 1
P3-P5 VJS4064N160E CONNECTOR (FEMALE) 3 K1KAG0A00006 C83-87 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 5
P7 VJP2824B003 CONNECTOR (MALE) 1 K1KA03B00005 C88 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
P8 VJP2824A002 CONNECTOR (MALE) 1 K1KA02A00009 C89,90 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
ELECTRICAL REPLACEMNT PARTS LIST (AJ-CA900HP/EN)
PRT-10
To Next Page
