Panasonic DVCPRO AJ-CA901P - Electrical Replacemnt Parts List (Aj-Ca901 P)

Components identified with the mark  have special characteristics for safety.
When replacing any of these component, use only the same type.
ELECTRICAL REPLACEMENT PARTS LIS
T
AJ-CA901P
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
P9 VJP2741A004 CONNECTOR (MALE) 1 K1KA04A00236
 E1
VEP20816A CAM MOTHER P.C.BOARD 1 (RTL) P10 VJP4395D002 CONNECTOR (MALE) 1
P11 VJP4395D003 CONNECTOR (MALE) 1
 E2
VEP23516C CAM DIGITAL P.C.BOARD 1 (RTL) P12 VJP4395D014 CONNECTOR (MALE) 1
P13 VJP4395D015 CONNECTOR (MALE) 1
 E3
VEP21250A CAM POWER P.C.BOARD 1 (RTL) P14 VJP4395B006 CONNECTOR (MALE) 1
P15 VJP4395D004 CONNECTOR (MALE) 1
 E4
VEP24165A CAM ICOM P.C.BOARD 1 (RTL) P16 VJP4395D008 CONNECTOR (MALE) 1
 E5
VEP20817A CAM RET P.C.BOARD 1 (RTL) R1-R4 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 4
 E6
VEP20A38A CAM IF P.C.BOARD 1 (RTL)

TH1 D4ZZ00000018 THERMISOTR 1
 E7
VEP20835A CAM DCIN P.C.BOARD 1 (RTL)
 E8
VEP27216A CAM RF U P.C.BOARD 1 (RTL)
 E9
VEP20834A CAM RIL U P.C.BOARD 1 (RTL)
 E2
VEP23516C CAM DIGITAL P.C.BOARD 1 (RTL)
C1 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C2 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C3 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C4 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C6 ECUM1E224ZFN C.CAPACITOR CH 25V 0.22U 1
C7-10 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4
C11 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
C12,13 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C14,15 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
C16,17 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C18 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C19 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C20 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
 E1
VEP20816A CAM MOTHER P.C.BOARD 1 (RTL) C21 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C22 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C24 ECUM1E224ZFN C.CAPACITOR CH 25V 0.22U 1
D1 S3V60 DIODE 1 B0EAKR000020 C25-28 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4
C29 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
J1 VEE0S43 CABLE 1 C30,31 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C32,33 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
L6 J0JKC0000009 FILTER 1 C34,35 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
L11 J0JBC0000019 FILTER 1 C36 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
L12 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C37 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
L13 J0JBC0000019 FILTER 1 C38,39 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
L14 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C40 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
L15 J0JBC0000019 FILTER 1 C41 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
L16 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C42,43 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
L17-21 J0JBC0000019 FILTER 5 C44 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
L22 J0JKC0000009 FILTER 1 C45 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
L23 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C46 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
L24 J0JBC0000019 FILTER 1 C48 ECUM1E224ZFN C.CAPACITOR CH 25V 0.22U 1
L25 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C49-52 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4
L26 J0JBC0000019 FILTER 1 C53 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
L27 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C54,55 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
L28 J0JBC0000019 FILTER 1 C56,57 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
L29 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C58,59 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
L30-34 J0JBC0000019 FILTER 5 C60,61 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
L35 J0JKC0000009 FILTER 1 C62-67 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 6
L36 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C68 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
L37-40 J0JBC0000019 FILTER 4 C69 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
L41 J0JKC0000009 FILTER 1 C70 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
L42 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C71-73 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3
L43,44 J0JBC0000019 FILTER 2 C74 ECJ1VB1H103K C.CAPACITOR CH 50V 0.01U 1
L45 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C75 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
L46-49 J0JBC0000019 FILTER 4 C76 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
L50 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C77 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
L51 J0JKC0000009 FILTER 1 C79 ECST0JC686 T.CAPACITOR CH6.3V 68U 1
L52 J0JBC0000019 FILTER 1 C80 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
L53 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C81 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C82 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
P1 VJS4064N070E CONNECTOR 1 C83-87 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 5
P2 K1KA02A00009 CONNECTOR (MALE) 1 C88 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
P3-P5 VJS4064N160E CONNECTOR (FEMALE) 3 K1KAG0A00006 C89,90 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
P7 VJP2824B003 CONNECTOR (MALE) 1 K1KA03B00005 C91 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
P8 K1KA02A00009 CONNECTOR (MALE) 1 C92-95 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4
EPL-1
