Panasonic DVCPRO AJ-CA901P - Electrical Replacemnt Parts List (Aj-Bs900 Hp;En)

Ref.No. Part No. Part Name & Description Pc
s
Remarks Ref.No. Part No. Part Name & Description Pc
s
Remarks
L60 VLP0147 COIL 1 J0JBC0000041
E1 VEP20818A BS MOTHER P.C.BOARD 1 (RTL) L61-65 VLP0353 COIL 5
L66 VLP0147 COIL 1 J0JBC0000041
E2 VEP23518A BS DIGITAL P.C.BOARD 1 (RTL)FOR AJ-BS900HP L67 VLP0353 COIL 1
VEP20885A BS DIGITAL SUB P.C.BOARD 1 (RTL)FOR VEP23518A
VEP23533A SET UP SUB P.C.BOARD 1
(
RTL
)
FOR VEP23518
(
RTL
)
FOR SU P1-P4 VJS4064N160E CONNECTOR (FEMALE) 4 K1KAG0A00006
E2 VEP23518B BS DIGITAL P.C.BOARD 1 (RTL)FOR AJ-BS900HEN P5 VJP3969A037 CONNECTOR 1
VEP20885A BS DIGITAL SUB P.C.BOARD 1 (RTL)FOR VEP23518B P6 VJP2824A004 CONNECTOR (MALE) 1 K1KA04A00005
P7 VJP2741A006 CONNECTOR (MALE) 1 K1KA06A00212
E3 VEP24166A BS AUDIO P.C.BOARD 1 (RTL)FOR AJ-BS900HP P8 VJP4395D008 CONNECTOR (MALE) 1
E3 VEP24166B BS AUDIO P.C.BOARD 1 (RTL)FOR AJ-BS900HEN P9 VJS3826C030 CONNECTOR (FEMALE) 1
P10 VJP2741A004 CONNECTOR (MALE) 1 K1KA04A00236
E4 VEP21248A BS POWER P.C.BOARD 1 (RTL) P11 VJS3826A010 CONNECTOR (FEMALE) 1
P12 VJP4395D010 CONNECTOR (MALE) 1
E5 VEP21249A BS AC FILTER P.C.BOARD 1 (RTL) P13 VJP4395D007 CONNECTOR (MALE) 1
P14 VJP4395D010 CONNECTOR (MALE) 1
E6 VEP20819A BS FRONT P.C.BOARD 1 (RTL) P15 VJP4395D011 CONNECTOR (MALE) 1
P16 VJP4395D012 CONNECTOR (MALE) 1
E7 VEP21251A BS POWER IF P.C.BOARD 1 (RTL) P17 VJS3826C024 CONNECTOR (FEMALE) 1
E8 VEP24163A BS ICOM P.C.BOARD 1 (RTL)
E9 VEP20840B BS AUDIO CN P.C.BOARD 1 (RTL)
E10 VEP20833A BS COMM P.C.BOARD 1 (RTL) E2 VEP23518A BS DIGITAL P.C.BOARD 1 (RTL)FOR AJ-BS900HP
VEP20885A BS DIGITAL SUB P.C.BOARD 1 (RTL)FOR VEP23518A
E11 VEP20832A BS REAR P.C.BOARD 1 (RTL) VEP23533A SETUP SUB P.C.BOARD 1 (RTL)FOR VEP23518A
E2 VEP23518B BS DIGITAL P.C.BOARD 1 (RTL)FOR AJ-BS900HEN
E12 VEP26248A BS ECU LED P.C.BOARD 1 (RTL) VEP20885A BS DIGITAL SUB P.C.BOARD 1 (RTL)FOR VEP23518B
E13 VEP27214A BS RF ASS'Y 1 (RTL)
C1 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1 FOR SUB1 P.C.BOARD
C1 02 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
C2 ECST1AY106 T.CAPACITOR CH 10V 10U 1 FOR SUB1 P.C.BOARD
C2 02 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C3 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1 FOR SUB1 P.C.BOARD
C3 02 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1
C4 ECST1AY106 T.CAPACITOR CH 10V 10U 1 FOR SUB1 P.C.BOARD
C4 02 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1
C5 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C7,C8 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
C9 ECUX1H472KBV C.CAPACITOR CH 50V 4700P 1
C10 ECUX1H153KBV C.CAPACITOR CH 50V 0.015U 1
C11 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C12,13 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
C14 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
E1 VEP20818A BS MOTHER P.C.BOARD 1 (RTL) C15,16 ECST1VY104 T.CAPACITOR CH 35V 0.1U 2
C17 ECST1AY106 T.CAPACITOR CH 10V 10U 1
C18 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
C41,42 EEVHB1E330P E.CAPACITOR 25V 33U 2 C19 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C20 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
IC1 AN7712SP IC 1 C21 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C22,23 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L1 VLP0147 COIL 1 J0JBC0000041 C24 ECST1CY475 T.CAPACITOR CH 16V 4.7U 1
L2,L3 VLP0353 COIL 2 C25-27 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 3
L4 VLP0147 COIL 1 J0JBC0000041 C28,29 ECST1AY106 T.CAPACITOR CH 10V 10U 2
L5-10 VLP0353 COIL 6 C30 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L11 J0JKC0000009 FILTER 1 C31 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L12,13 VLP0353 COIL 2 C32 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L14 J0JKC0000009 FILTER 1 C33 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L15 VLP0147 COIL 1 J0JBC0000041 C34-37 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 4
L16-18 VLP0353 COIL 3 C38 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L19 VLP0147 COIL 1 J0JBC0000041 C39,40 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L20-26 VLP0353 COIL 7 C41 ECST1AY106 T.CAPACITOR CH 10V 10U 1
L27,28 J0JKC0000009 FILTER 2 C42 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
L29-34 VLP0353 COIL 6 C43 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
L35 VLP0147 COIL 1 J0JBC0000041 C44,45 ECST1AY106 T.CAPACITOR CH 10V 10U 2
L36,37 J0JKC0000009 FILTER 2 C46,47 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L38-45 VLP0353 COIL 8 C48-50 ECUX1H101JCV C.CAPACITOR CH 50V 100P 3
L46 VLP0147 COIL 1 J0JBC0000041 C51 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
L47 VLP0353 COIL 1 C52 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
L48 VLP0147 COIL 1 J0JBC0000041 C53 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
L49 VLP0353 COIL 1 C54 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
L50 VLP0147 COIL 1 J0JBC0000041 C55,56 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
L51-59 VLP0353 COIL 9 C57-59 ECUX1H101JCV C.CAPACITOR CH 50V 100P 3
ELECTRICAL REPLACEMNT PARTS LIST (AJ-BS900HP/EN)
PRT-16
