Panasonic DVCPRO AJ-CA901P - Electrical Replacemnt Parts List (Aj-Bs901 En;MC)

Components identified with the mark  have special characteristics for safety.
When replacing any of these component, use only the same type.
ELECTRICAL REPLACEMENT PARTS LIS
T
AJ-BS901EN/MC
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
C42 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
 E1
VEP20818A BS MOTHER P.C.BOARD 1 (RTL) C43 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C44,45 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
 E2
VEP23518F BS DIGITAL P.C.BOARD 1 (RTL) C46,47 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2

VEP20885A BS DIGITAL SUB P.C.BOARD 1 (RTL)FOR VEP23518F C48-50 ECUX1H101JCV C.CAPACITOR CH 50V 100P 3
C51 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
 E3
VEP24184B BS AUDIO P.C.BOARD 1 (RTL) C52 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
C53 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
 E4
VEP21288A BS POWER P.C.BOARD 1 (RTL) C54 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C55,56 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
 E5
VEP21249A BS AD FILTER P.C.BOARD 1 (RTL) C57-59 ECUX1H101JCV C.CAPACITOR CH 50V 100P 3
C60 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
 E6
VEP20819C BS FRONT P.C.BOARD 1 (RTL) C61 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
C62 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
 E7
VEP21251A BS POWER IF P.C.BOARD 1 (RTL) C63 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C64,65 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
 E8
VEP24163C BS INCOM P.C.BOARD 1 (RTL) C66 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C67,68 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
 E9
VEP20840B BS AUDIO P.C.BOARD 1 (RTL) C69 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C70 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
 E10
VEP20833A BS COMM P.C.BOARD 1 (RTL) C71 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C72,73 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
 E11
VEP20832A BS REAR P.C.BOARD 1 (RTL) C74,75 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C76-78 ECUX1H101JCV C.CAPACITOR CH 50V 100P 3
 E12
VEP26248A BS ECU LED P.C.BOARD 1 (RTL) C79 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
C80 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
 E13
VEP27214A BS RF U P.C.BOARD 1 (RTL) C81 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
C82 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C83,84 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C85-87 ECUX1H101JCV C.CAPACITOR CH 50V 100P 3
C88 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
C89 ECUX1H681JCV C.CAPACITOR CH 50V 680P 1
C90 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1
C91 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C92-94 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3
C95 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C96 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C97 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C98 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
 E2
VEP23518F BS DIGITAL P.C.BOARD 1 (RTL) C99 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C100-03 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4
C104,05 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
C1 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 FOR VEP20885A C106,07 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C1 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 C108,09 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2
C2 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 FOR VEP20885A C110 ECUX1H102JCV C.CAPACITOR CH 50V 1000P 1
C2 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 C111 ECUX1H471JCV C.CAPACITOR CH 50V 470P 1
C3 ECJ1VB1H103K C.CAPACITOR CH 50V 0.01U 1 C112 ECUX1H153KBV C.CAPACITOR CH 50V 0.015U 1
C3 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 FOR VEP20885A C115,16 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C4 ECJ1VB1H103K C.CAPACITOR CH 50V 0.01U 1 C117 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C4 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 FOR VEP20885A C118 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C5 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1 C119,20 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
C7,C8 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2 C121-27 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 7
C9 ECUX1H472KBV C.CAPACITOR CH 50V 4700P 1 C128,29 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
C10 ECUX1H153KBV C.CAPACITOR CH 50V 0.015U 1 C130-32 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3
C11 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1 C133,34 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2
C12,13 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2 C135-40 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 6
C14 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 C141 ECST1AY106Z T.CAPACITOR CH 10V 10U 1
C15,16 ECST1VY104 T.CAPACITOR CH 35V 0.1U 2 C142 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C17 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 C143,44 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
C18 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 C145,46 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
C19 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 C147,48 ECST1AY106Z T.CAPACITOR CH 10V 10U 2
C20 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 C149-51 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3
C21 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 C152 ECJ1VB1H103K C.CAPACITOR CH 50V 0.01U 1
C22,23 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2 C153 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C24 ECST1CY475 T.CAPACITOR CH 16V 4.7U 1 C154 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C25-27 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3 C155 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C28,29 ECST1AY106Z T.CAPACITOR CH 10V 10U 2 C156 ECUX1H271JCV C.CAPACITOR CH 50V 270P 1
C30 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 C157 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C31 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 C158 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C32 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 C159 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C33 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 C162 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
C34-37 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4 C163 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
C38 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 C164 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C39,40 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2 C165 ECUX1H271JCV C.CAPACITOR CH 50V 270P 1
C41 ECST1AY106Z T.CAPACITOR CH 10V 10U 1 C166 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
EPL-21
