Components identified with the mark have special characteristics for safety.
When replacing any of these component, use only the same type.
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
L3 VLQ0400 COIL 1 R53,54 ERJ3RBD103 M.RESISTOR CH 1/16W 10K 2
L4,L5 VLQ0417 COIL 10UH 2 R55 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
L6 VLQ0400 COIL 1 R56 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
L7 J0JKC0000009 FILTER 1 R57 ERJ3RBD303 M.RESISTOR CH 1/16W 30K 1
L8 VLQ0417 COIL 10UH 1 R58 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K 1
L9,10 J0JKC0000009 FILTER 2 R59 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1
L11-13 J0JBC0000041 FILTER 3 R60 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
L14 J0JKC0000009 FILTER 1 R61 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
L15 J0JBC0000041 FILTER 1 R62,63 ERJ3RBD103 M.RESISTOR CH 1/16W 10K 2
R64 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1
P1 VJP4064Q160 CONNECTOR (MALE) 1 K1KBG0B00002 R65 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R66 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
Q1 2SD0601ARL TRANSISTOR 1 R67 ERJ3RBD103 M.RESISTOR CH 1/16W 10K 1
Q2 UN2215 TRANSISTOR-RESISTOR 1 R68 ERJ3RBD303 M.RESISTOR CH 1/16W 30K 1
Q3,Q4 2SD0601ARL TRANSISTOR 2 R71 ERJ3RBD153 M.RESISTOR CH 1/16W 15K 1
Q5 2SB0709A0L TRANSISTOR 1 R72 ERJ3GEYJ432 M.RESISTOR CH 1/16W 4.3K 1
Q6 2SJ245S TRANSISTOR 1 R73 ERJ3GEYJ681 M.RESISTOR CH 1/16W 680 1
Q7 2SB0709A0L TRANSISTOR 1 R74 ERJ3RBD473 M.RESISTOR CH 1/16W 47K 1
Q8 2SD0601ARL TRANSISTOR 1 R75 ERJ3RBD123 M.RESISTOR CH 1/16W 12K 1
Q9 2SB0709A0L TRANSISTOR 1 R76 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
Q10 2SJ245S TRANSISTOR 1 R77,78 ERJ3GEYJ204 M.RESISTOR CH 1/16W 200K 2
Q11 2SD0601ARL TRANSISTOR 1 R79-82 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 4 D0GB103JA002
Q12 2SB09560HL TRANSISTOR 1 R83,84 ERJ6GEYJ201 M.RESISTOR CH 1/10W 200 2
Q13 2SD1280 TRANSISTOR 1 R86 ERJ3GEYJ433 M.RESISTOR CH 1/16W 43K 1
Q14-16 2SB09560HL TRANSISTOR 3 R87,88 ERJ6GEYJ201 M.RESISTOR CH 1/10W 200 2
R90 ERJ3GEYJ433 M.RESISTOR CH 1/16W 43K 1
R1 ERJ3RBD362 M.RESISTOR CH 1/16W 3.6K 1 R91 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R2 ERW2PKR10 W.RESISTOR 2W 0.1 1 R92 ERJ3GEYJ273 M.RESISTOR CH 1/16W 27K 1
R3 ERJ3RBD432 M.RESISTOR CH 1/16W 4.3K 1 R93 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R4 ERJ3RBD104 M.RESISTOR CH 1/16W 100K 1 R94,95 ERJ3GEYJ100 M.RESISTOR CH 1/16W 10 2
R5,R6 ERJ3GEYJ334 M.RESISTOR CH 1/16W 330K 2 R96,97 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 2
R7 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002 R98 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 1
R8 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K 1 R99,00 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002
R9 ERJ3RBD203 M.RESISTOR CH 1/16W 20K 1 R101 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 1
R10 ERJ3RBD683 M.RESISTOR CH 1/16W 68K 1 R102 ERJ3GEYJ622 M.RESISTOR CH 1/16W 6.2K 1
R11 ERJ3RBD223 M.RESISTOR CH 1/16W 22K 1 R103 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R12 ERJ3RBD202 M.RESISTOR CH 1/16W 2K 1 R104 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R13 ERJ3RBD683 M.RESISTOR CH 1/16W 68K 1 R105 ERJ3GEYJ163 M.RESISTOR CH 1/16W 16K 1
R14 ERJ3RBD223 M.RESISTOR CH 1/16W 22K 1 R106 ERJ3GEYJ362 M.RESISTOR CH 1/16W 3.6K 1
R15 ERJ3RBD112 M.RESISTOR CH 1/16W 1.1K 1 R107 ERJ3GEYJ273 M.RESISTOR CH 1/16W 27K 1
R16 ERJ3RBD183 M.RESISTOR CH 1/16W 18K 1 R108,09 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002
R17 ERJ3RBD153 M.RESISTOR CH 1/16W 15K 1 R110 ERJ3GEYJ133 M.RESISTOR CH 1/16W 13K 1
R18 ERJ3RBD333 M.RESISTOR CH 1/16W 33K 1 R111,12 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002
R19 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 R146,47 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 2
R20 ERJ3RBD182 M.RESISTOR CH 1/16W 1.8K 1
R21 ERJ3RBD133 M.RESISTOR CH 1/16W 13K 1 SW1 CAS-120B SWITCH 1
R22 ERJ3GEYJ273 M.RESISTOR CH 1/16W 27K 1
R23 ERJ3RBD113 M.RESISTOR CH 1/16W 11K 1 VR1 VRV0303B502 V.RESISTOR 5K 1
R25 ERJ3RBD563 M.RESISTOR CH 1/16W 56K 1 VR2,R3 VRV0303B103 V.RESISTOR 10K 2
R26 ERJ3RBD303 M.RESISTOR CH 1/16W 30K 1
R27 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1 MISCELLANEOUS
R28 ERJ3RBD753 M.RESISTOR CH 1/16W 75K 1
R29 ERJ3RBD223 M.RESISTOR CH 1/16W 22K 1 VSC5316 SHIELD CASE (PWR) 1
R30 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1 VSC5317 SHIELD CASE COVER (PWR) 1
R31 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K 1 XYN2+J6 SCREW 2
R32 ERJ3GEYJ182 M.RESISTOR CH 1/16W 1.8K 1
R33 ERJ3GEYJ181 M.RESISTOR CH 1/16W 180 1
R34 ERJ3GEYJ105 M.RESISTOR CH 1/16W 1M 1
R35 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K 1
R36 ERJ3GEYJ121 M.RESISTOR CH 1/16W 120 1
R37 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
E6
VEP20A38A CAM IF P.C.BOARD 1 (RTL)
R38 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1
R39 ERQ16NKR10 F.RESISTOR 0.1 1
R40 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K 1 P101 K1KAA0A00110 CONNECTOR (MALE) 1
R41 ERJ3GEYJ182 M.RESISTOR CH 1/16W 1.8K 1 P102 VJP4064Q070 CONNECTOR 1
R42 ERJ3GEYJ181 M.RESISTOR CH 1/16W 180 1
R43 ERJ3GEYJ105 M.RESISTOR CH 1/16W 1M 1 MISCELLANEOUS
R44 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K 1
R45 ERJ3GEYJ121 M.RESISTOR CH 1/16W 120 1 XSB2+6FX SCREW 2
R46,47 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 2
R48 ERJ3RBD153 M.RESISTOR CH 1/16W 15K 1
R49 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K 1
R50 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1
R51 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R52 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
EPL-20
