Panasonic DVCPRO AJ-CA901P - Electrical Replacemnt Parts List (Aj-Rp900 P;En)

Ref.No. Part No. Part Name & Description Pc
s
Remarks Ref.No. Part No. Part Name & Description Pc
s
Remarks
E1 VEP21252A RPT-PS P.C.BOARD 1 (RTL)
E2 VEP27217A RPT-RF P.C.BOARD 1 (RTL)
E3 VEP20839B DUPLEXER P.C.BOARD 1 (RTL)
E3 VEP20839B DUPLEXER P.C.BOARD 1 (RTL)
E4 VEP20839A DUPLEXER P.C.BOARD 1 (RTL) C01 ECUX1H040CCV C.CAPACITOR CH 50V 4P 1
C02 ECUX1H150JCV C.CAPACITOR CH 50V 15P 1
E5 VEP23526A PRT-SDI P.C.BOARD 1 (RTL) C03,04 ECUX1H020CCV C.CAPACITOR CH 50V 2P 2
C05 ECUX1H040CCV C.CAPACITOR CH 50V 4P 1
C06 ECUX1H1R5CC
V
C.CAPACITOR CH 50V 1.5P 1
C07 ECUX1H010CCV C.CAPACITOR CH 50V 1P 1
C08,09 ECUX1H040CCV C.CAPACITOR CH 50V 4P 2
C10 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C11 ECUX1H0R5CC
V
C.CAPACITOR CH 50V 0.5P 1
C12 ECUX1H060DCV C.CAPACITOR CH 50V 6P 1
C13 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C14 ECUX1H050CCV C.CAPACITOR CH 50V 5P 1
C15 ECUX1H040CCV C.CAPACITOR CH 50V 4P 1
E1 VEP21252A PRT-PS P.C.BOARD 1 (RTL) C16 ECUX1H060DCV C.CAPACITOR CH 50V 6P 1
C17 ECUX1H020CCV C.CAPACITOR CH 50V 2P 1
C18 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C04,05 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
F1 K5JJBB000012 BREAKER 1
J5 VJP3950F004 CONNECTOR 1
J6 VJP3950F002 CONNECTOR 1
E4 VEP20839A DUPLEXER P.C.BOARD 1 (RTL)
C01 ECUX1H020CCV C.CAPACITOR CH 50V 2P 1
C02 ECUX1H150JCV C.CAPACITOR CH 50V 15P 1
C03,04 ECUX1H020CCV C.CAPACITOR CH 50V 2P 2
E2 VEP27217A RPT-RF P.C.BOARD 1 (RTL) C05 ECUX1H040CCV C.CAPACITOR CH 50V 4P 1
C06 ECUX1H1R5CC
V
C.CAPACITOR CH 50V 1.5P 1
C07 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C01 ECUX1H331JCV C.CAPACITOR CH 50V 330P 1 C08,09 ECUX1H040CCV C.CAPACITOR CH 50V 4P 2
C02 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1 C10 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C03 ECUX1H331JCV C.CAPACITOR CH 50V 330P 1 C11 ECUX1H0R5CC
V
C.CAPACITOR CH 50V 0.5P 1
C04 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1 C12 ECUX1H060DCV C.CAPACITOR CH 50V 6P 1
C05 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C13 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C06 ECUX1H331JCV C.CAPACITOR CH 50V 330P 1 C14 ECUX1H050CCV C.CAPACITOR CH 50V 5P 1
C07 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1 C15 ECUX1H040CCV C.CAPACITOR CH 50V 4P 1
C08,09 ECUX1H331JCV C.CAPACITOR CH 50V 330P 2 C16 ECUX1H060DCV C.CAPACITOR CH 50V 6P 1
C10 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1 C17 ECUX1H020CCV C.CAPACITOR CH 50V 2P 1
C11 ECUX1H331JCV C.CAPACITOR CH 50V 330P 1 C18 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C12 ECUX1H030CCV C.CAPACITOR CH 50V 3P 1
C13,14 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 2
C15 ECUX1H040CCV C.CAPACITOR CH 50V 4P 1
C16,17 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 2
C18 ECUX1H331JCV C.CAPACITOR CH 50V 330P 1
C19 ECUX1H1R5CC
V
C.CAPACITOR CH 50V 1.5P 1 E5 VEP23526A RPT-SDI P.C.BOARD 1 (RTL)
C21 ECUX1H331JCV C.CAPACITOR CH 50V 330P 1
C23 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 1
C24 EEVHB1A101P E.CAPACITOR 10V 100U 1 C01 EEVHB1A101P E.CAPACITOR 10V 100U 1
C26 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1 C02 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
C27 EEVHB1A101P E.CAPACITOR 10V 100U 1 C03,04 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 2
C28-30 ECUX1H102KBV C.CAPACITOR CH 50V 1000P 3 F1H1H102A009 C05 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
C06-10 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 5
J5 VJP3950F004 CONNECTOR 1 C11 ECUX1H152KBV C.CAPACITOR CH 50V 1500P 1
J6 VJP3950F002 CONNECTOR 1 C12 ECUX1H150JCV C.CAPACITOR CH 50V 15P 1
C13 ECUX1H472KBV C.CAPACITOR CH 50V 4700P 1
R01,02 ERJ3GEYJ910 M.RESISTOR CH 1/16W 91 2 C14-22 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 9
R05 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C24,25 ECUX1C105KBN C.CAPACITOR CH 10V 1U 2
R08,09 ERJ3GEYJ910 M.RESISTOR CH 1/16W 91 2 C26,27 ECUX1H020CCV C.CAPACITOR CH 50V 2P 2
R10 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C28,29 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
R13 ERJ3GEYJ510 M.RESISTOR CH 1/16W 51 1
R17 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1 J3 VJP3950F003 CONNECTOR 1
R18 ERJ3GEYG332 M.RESISTOR CH 1/16W 3.3K 1 J4 VJP3950F002 CONNECTOR 1
R19 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
R20 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1 R01-04 ERJ6GEYG750 M.RESISTOR CH 1/10W 75 4
R22 ERJ3GEYJ470 M.RESISTOR CH 1/16W 47 1 R05,06 ERJ6GEYG471 M.RESISTOR CH 1/10W 470 2
R24 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 R07 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
R08 ERJ6GEYJ510 M.RESISTOR CH 1/10W 51 1
ELECTRICAL REPLACEMNT PARTS LIST (AJ-RP900P/EN)
PRT-31
