Panasonic DVCPRO AJ-CA901P - Page 263

Ref.No. Part No. Part Name & Description Pc
s
Remarks Ref.No. Part No. Part Name & Description Pc
s
Remarks
E10 VEP20833A BS COMM P.C.BOARD 1 (RTL)
E12 VEP26248A BS ECU LED P.C.BOARD 1 (RTL)
J102 VJS3826C024 CONNECTOR (FEMALE) 1
J204 VJP3277A024 COMMUNICATION CONNECTOR 1 K1AA124H0003
D1-D3 LA-301MBM DIODE 3 B3BB1C000001
W1 VEE0L88 CABLE 1
E11 VEP20832A BS REAR P.C.BOARD 1 (RTL)
C1-C5 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 5
C6,C7 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2
C8,C9 EEVHB1A101P E.CAPACITOR 10V 100U 2
CR1 1SS355TE17 DIODE 1 B0ACCK000005
J101 VJS3826C030 CONNECTOR (FEMALE) 1
L1,L2 A921CY-470M FILTER 2
L3 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L4 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L5 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L6 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L7 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L8 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L9 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L10 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L11 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L12 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L13 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L14 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L15 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L16 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L17 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L18 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L19 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L20 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L21 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L22 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L23 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L24 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L25 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L26 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L27 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L28 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L29 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L30 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L31 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L32 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
L33 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
L34 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
Q1 2SC2295-C TRANSISTOR 1
R1 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
R2 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R3 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R4 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R5 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R6 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R7 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R8,R9 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002
R10 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R11 ERJ3GEYJ470 M.RESISTOR CH 1/16W 47 1
R12 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
U1 C0JBAR000264 IC 1
U2 C0ABBB000158 IC 1 C0ABBA000045
U3 AD847JR IC 1 C0ABAB000065
PRT-30
