Panasonic DVCPRO AJ-CA901P - Page 262

Ref.No. Part No. Part Name & Description Pc
s
Remarks Ref.No. Part No. Part Name & Description Pc
s
Remarks
R99 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 C1005 ECST1EC106 T.CAPACITOR CH 25V 10U 1
R101 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 C1006 ECUX1H680JCV C.CAPACITOR CH 50V 68P 1
R102 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 C1007 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1
R104 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 C1008 ECST1EC106 T.CAPACITOR CH 25V 10U 1
R105 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 C1009 ECST1CC226 T.CAPACITOR CH 16V 22U 1
R107 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 C1010 ECUX1H820JCV C.CAPACITOR CH 50V 82P 1
R108 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 C1012 ECUX1H820JCV C.CAPACITOR CH 50V 82P 1
R110 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 C1013 ECST1EC106 T.CAPACITOR CH 25V 10U 1
R111 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 C1014,15 ECST1CY225 T.CAPACITOR CH 16V 2.2U 2
R113 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 C1016 EEVHB1E330P E.CAPACITOR 25V 33U 1
R114 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
R116 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 D1001 LN38GPL DIODE 1
R117 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 D1002-04 LN28RPL DIODE 3
R119 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 D1005,06 LN38GPL DIODE 2
R120 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
R122 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 IC1001 AN77L08M IC 1
R123 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 IC1002 UPC4570G2 IC 1 C0ABBB000016
R125 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1 IC1003 AN77L08M IC 1
R126 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1 IC1004 UPC4560G IC 1
R128-34 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 7
R135 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 L1005 J0JKC0000009 FILTER 1
L1008,09 J0JKC0000009 FILTER 2
SW1 CMS-2202A SWITCH 1
SW2 K9AA020A0001 SWITCH 1 P1001 VJP2741A020 CONNECTOR (MALE) 1 K1KA20A00056
SW3 VSS0367-08B SWITCH 1 P1002 VJP2741A006 CONNECTOR (MALE) 1 K1KA06A00212
SW4 VST0153 SWITCH 1 K0E112A00098
SW5 KSR1007 SWITCH 1 R1001 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1 D0GB102JA002
SW6 KSR1005 SWITCH 1 R1002 ERJ3GEYJ562 M.RESISTOR CH 1/16W 5.6K 1
SW7 VST0152 SWITCH 1 K0E112A00094 R1003 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
SW8 K0F111A00397 SWITCH 1 R1004,05 ERJ3GEYJ333 M.RESISTOR CH 1/16W 33K 2
SW9 K0F111A00398 SWITCH 1 R1006 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K 1
SW10 K0F111A00399 SWITCH 1 R1007 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
SW11 VSP0853A004 SWITCH 1 K0F111A00239 R1008 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K 1
SW12 K0F111A00400 SWITCH 1 R1009 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
SW13 K0F111A00401 SWITCH 1 R1010,11 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 2
SW14-20 VSP0853A000 SWITCH 7 K0F111A00235 R1012,13 ERJ3GEYJ333 M.RESISTOR CH 1/16W 33K 2
SW21 VSP0853A001 SWITCH 1 K0F111A00236 R1014-16 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 3 D0GB103JA002
SW22 VSP0853A002 SWITCH 1 K0F111A00237 R1017-28 ERJ3GEYJ821 M.RESISTOR CH 1/16W 820 12
SW23-25 VSP0853A000 SWITCH 3 K0F111A00235 R1029,30 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 2
R1031-33 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 3
TH1 D4FB1R100001 THERMISTOR 1 R1034 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0 1
VR1-R5 VRV0118B103 V.RESISTOR 10K 5 SW1001 M-2019L/S-P4 SWITCH 1
VR6 D2BDA14B0004 V.RESISTOR 10K 1 SW1002 CMS-2202A SWITCH 1
VR7-10 VRV0118B103 V.RESISTOR 10K 4 SW1003 VST0153 SWITCH 1 K0E112A00098
SW1004 VSP0853A004 SWITCH 1 K0F111A00239
X1 VSX0624 CRYSTAL OSCILLATOR 1 H2C800400001 SW1005 VSP0853A003 SWITCH 1 K0F111A00238
SW1006 VST0152 SWITCH 1 K0E112A00094
MISCELLANEOUS
VR1001 VRV0303B104A V.RESISTOR 100K 1
VMX2148 LED SPACER 6 VR1002,03 VRV0118B102 V.RESISTOR 1K 2
XD1001-06 VMX2148 LED SPACER 6
MISCELLANEOUS
E7 VEP21251A BS POWER IF P.C.BOARD 1 (RTL) VMA0M49 SWITCH ANGLE A 1
XWE6 WASHER 8
P2001 SDCB-37S CONNECTOR 1
P2002 VJP2741A016 CONNECTOR (MALE) 16P 1 K1KA16A00139
P2003 VJP2741A022 CONNECTOR (MALE) 1 K1KA22A00041
P2004 VJP2739B002 CONNECTOR (MALE) 1 K1KA02B00127
E9 VEP20840B BS AUDIO CN P.C.BOARD 1 (RTL)
J103 VJS3826A010 CONNECTOR (FEMALE) 1
J205,06 VJP2666 CONNECTOR 2 K1AA103A0001
E8 VEP24163A BS ICOM P.C.BOARD 1 (RTL)
R2 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R4 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
C1001 EEVHP1E4R7 E.CAPACITOR 25V 4.7U 1 R6 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
C1002 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 R8 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
C1003 ECST1EC106 T.CAPACITOR CH 25V 10U 1
C1004 ECUX1H680JCV C.CAPACITOR CH 50V 68P 1
PRT-29
