Panasonic DVCPRO AJ-CA901P - Page 261

Ref.No. Part No. Part Name & Description Pc
s
Remarks Ref.No. Part No. Part Name & Description Pc
s
Remarks
L1 ELF18D604F FILTER 1 IC3 SN75C1168NS IC 1
IC4 AK6440AF IC 1
P1 VJP2824A005 CONNECTOR (MALE) 1 K1KA05A00089 IC5 C0JBAZ000279 IC 1
P2 VJP4396B002 CONNECTOR (MALE) 1 IC6 HD64F3048F16 IC 1 C2CBHF000009
P5 VJP2739A002 CONNECTOR (MALE) 1 K1KA02A00225 IC7 AN90B20S IC 1
P6 VJP4396B002 CONNECTOR (MALE) 1 IC8 TC7W53F IC 1
P7 VJP2739A002 CONNECTOR (MALE) 1 K1KA02A00225 IC9 C0JBAR000023 IC 1
IC10 C0JBAA000076 IC 1
Q1 2SD601A-R TRANSISTOR 1 IC11 C0EBH0000053 IC 1
Q2 UN2113 TRANSISTOR-RESISTOR 1 IC12,13 M66311FP IC 2 C0HBZ0000021
Q3 XN0460100L TRANSISTOR-RESISTOR 1
Q4 UN2212 TRANSISTOR-RESISTOR 1 ID6 VVVSI3552 SOFTWARE 1
R1 ERC12AGM334 S.RESISTOR 1/2W 330K 1 L1,L2 J0JKC0000009 FILTER 2
R2 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K 1 L3 VLQ0797221K COIL 220UH 1
R3 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 L4-L7 VLP0353 COIL 4
R4 ERJ3RBD273 M.RESISTOR CH 1/16W 27K 1 L8-12 VLP0147 COIL 5 J0JBC0000041
R5 ERJ3RBD472 M.RESISTOR CH 1/16W 4.7K 1 L13,14 VLP0353 COIL 2
R6 ERJ3GEYJ122 M.RESISTOR CH 1/16W 1.2K 1 L15,16 VLP0147 COIL 2 J0JBC0000041
R7,R8 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002 L17 VLP0353 COIL 1
R9 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K 1
R10 ERJ3GEYJ182 M.RESISTOR CH 1/16W 1.8K 1 P1 VJP4395D010 CONNECTOR (MALE) 1
R11-14 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 4 P2 VJP2739B005 CONNECTOR (MALE) 1 K1KA05B00106
R15 ERJ3GEYJ223 M.RESISTOR CH 1/16W 22K 1 P3 VJS3826A020 CONNECTOR (FEMALE) 1
R16 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1 P4 VJP4395D011 CONNECTOR (MALE) 1
RY1 VSY1033 RELAY 1 K6B1CGA00047 Q2 UN2215 TRANSISTOR-RESISTOR 1
Q3-Q5 2SB710A-S TRANSISTOR 3
MISCELLANEOUS
R1 ERX12SJR22 M.RESISTOR 1/2W 0.22 1
XSB3+8 SCREW 1 R2 ERJ3RBD122 M.RESISTOR CH 1/16W 1.2K 1
XWE3D8 WASHER 1 R3 ERJ3RBD362 M.RESISTOR CH 1/16W 3.6K 1
XWA3B WASHER 1 R4,R5 ERJ3GEYG472 M.RESISTOR CH 1/16W 4.7K 2
XNG3BS NUT 1 R6,R7 ERJ3GEYG471 M.RESISTOR CH 1/16W 470 2
VEE0M72 CABLE 1 R8 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1
VEE0N58 CABLE 1 R9 ER025CHF1500 M.RESISTOR 1/4W 150 1
R10 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1
R11 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1 D0GB102JA002
R13 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1
R14-18 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 5 D0GB103JA002
R19 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
E6 VEP20819A BS FRONT P.C.BOARD 1 (RTL) R22 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R23-26 EXB24V473J COMBI.R-R 47K 4
R27-34 ERJ3GEYJ391 M.RESISTOR CH 1/16W 390 8
C1 ECA1EHG101 E.CAPACITOR 25V 100U 1 R35-40 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 6 D0GB103JA002
C2 ECUX1H471JCV C.CAPACITOR CH 50V 470P 1 R41-44 EXB24V473J COMBI.R-R 47K 4
C3 ECA1CHG471 C.CAPACITOR 16V 470U 1 R45-48 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K 4
C4,C5 ECST1EY155 T.CAPACITOR CH 25V 1.5U 2 R49 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
C6 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 R50-57 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 8
C7,C8 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 2 R58,59 ERJ3GEYJ512 M.RESISTOR CH 1/16W 5.1K 2
C9 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 R60,61 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 2
C10,11 ECUX1H103KBV C.CAPACITOR CH 50V 0.01U 2 R62,63 ERJ3RBD273 M.RESISTOR CH 1/16W 27K 2
C12 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1 R64,65 ERJ3RBD153 M.RESISTOR CH 1/16W 15K 2
C13 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 R66,67 ERJ3RBD203 M.RESISTOR CH 1/16W 20K 2
C14 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1 R68,69 ERJ3RBD303 M.RESISTOR CH 1/16W 30K 2
C15 ECST1AY106 T.CAPACITOR CH 10V 10U 1 R70 ERJ3GEYJ330 M.RESISTOR CH 1/16W 33 1
C16-18 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 3 R71,72 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 2
C19 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 R73 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
C20,21 ECUX1H220JCV C.CAPACITOR CH 50V 22P 2 R74 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1
C22-31 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 10 R75 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
C32 ECST1CY475 T.CAPACITOR CH 16V 4.7U 1 R77 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
C33-35 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 3 R78 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
C36 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1 R80 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
C37 ECUX1E104ZFV C.CAPACITOR CH 25V 0.1U 1 R81 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
R83 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
D1 B0JCML000002 DIODE 1 R84 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
D2-D4 MA152K DIODE 3 R86 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
D6,D7 LN28RPL DIODE 2 R87 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
D8 LN38GPL DIODE 1 R89 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
D9 LN48YPL DIODE 1 R90 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
D10,11 LN38GPL DIODE 2 R92 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
D12-14 MA714 DIODE 3 R93 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
R95 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
IC1 NJM2360M IC 1 R96 ERJ3GEYJ513 M.RESISTOR CH 1/16W 51K 1
IC2 AN77L05M IC 1 R98 ERJ3GEYJ301 M.RESISTOR CH 1/16W 300 1
PRT-28
