communications terminated by "No Response". (Some of the communications terminated by "No
Response" were not displayed in the JOURNAL.)
When a fax transmission cannot be performed because the other party’s unit is set to the TEL
mode, "No response" will be printed.
6.6.6.2. JOURNAL 3
Refer to JOURNAL 3 in PRINTOUT EXAMPLE ().
Description
(6) ENCODE
Compression Code: MH/MR/MMR
(7) MSLT
MSLT means Minimum Scan Line Time. Used only at the factory.
(8) EQM
EQM means Eye Quality Monitor. Used only at the factory.
(9) ERROR LINE (RX)
When an error occurs while receiving a fax, this shows the number of error lines.
(10) MAKER CODE
This shows a 2 digit code of the other party's fax machine brand.
0E: “KX” model
00: Unknown
79: “UF” model
19: “Xerox” model
6.6.6.3. PRINTOUT EXAMPLE
124
