NO. SIGNAL I/O POWER
SUPPLIED
VOLTAGE
DESCRIPTION
101 RBA5 O 3.3V ROM/RAM BANK ADDRESS 5
102 RBA6/IOP96 O 3.3V A19
103 STB1 O 3.3V STROBE SIGNAL OUTPUT TO
THERMAL
HEAD
104 STB2 O 3.3V STROBE SIGNAL OUTPUT TO
THERMAL
HEAD
105 STB3 O 3.3V NOT USED
106 XRESET I 3.3V RESET INPUT
107 VDD (3.3V) ----- POWER SOURCE (+3.3V)
108 VSS GND POWER SOURCE (GND)
109 VSS GND POWER SOURCE (GND)
110 VDD (3.3V) ----- POWER SOURCE (+3.3V)
111 XORESET O 3.3V RESET OUTPUT
112 VDD(5V) 3.3V POWER SOURCE (+5V)
113 VSS GND POWER SOURCE (ANALOG GND)
114 XRESETI I 3.3V RESET INPUT
115 WDERR O 3.3V WATCHED ERROR OUTPUT SIGNAL
116 THDAT O 3.3V RECORDED IMAGE OUTPUT
117 THCLK O 3.3V CLOCK OUTPUT FOR DATA
TRANSFER
118 THLAT O 3.3V PULSE OUTPUT FOR DATA LATCH
119 STBNP I 3.3V INPUT PORT (TEST)
120 RM0/IOP O 3.3V RX MOTOR A PHASE
121 RM1/IOP O 3.3V RX MOTOR B PHASE
122 RM2/IOP O 3.3V RX MOTOR /A PHASE
123 RM3/IOP O 3.3V RX MOTOR /B PHASE
124 RXE/IOP O 3.3V RX MOTOR ENABLE SIGNAL
125 TMO O 3.3V TX MOTOR A PHASE
126 VDD (2.5V) 3.3V POWER SOURCE (+2.5V)
127 VSS GND POWER SOURCE (GND)
128 TM1/IOP O 3.3V TX MOTOR B PHASE
129 TM2/IOP O 3.3V TX MOTOR /A PHASE
130 TM3/IOP O 3.3V TX MOTOR /B PHASE
131 TXE/IOP O 3.3V TX MOTOR ENABLE SIGNAL
132 KSTART O 3.3V OPERATION PANEL CONTROL
133 KLATCH O 3.3V OPERATION PANEL CONTROL
134 KSCLK O 3.3V OPERATION PANEL CONTROL
135 KTXD O 3.3V OPERATION PANEL CONTROL
136 KRXD I 3.3V OPERATION PANEL CONTROL
137 FMEMCLK/IOP O 3.3V OUTPUT PORT (THON)
138 FMEMDI/IOP O 3.3V OUTPUT PORT (LINERLY)
139 ADSEL1 O 3.3V CHANNEL SELECT SIGNAL FOR AIN2
