Panasonic KX-TDA100

2.8 [1] Configuration
PC Programming Manual 109
DHLC8: 8-Port Digital Hybrid Extension
Card
KX-TDA100: 6
KX-TDA200: 8
2.8.4 [1-1] Slot—Card Property -
Extension Type
DLC8: 8-Port Digital Extension Card
DLC16: 16-Port Digital Extension Card
MSLC16: 16-Port Single Line Telephone
Extension with Message Lamp Card
SLC8: 8-Port Single Line Telephone
Extension Card
SLC16: 16-Port Single Line Telephone
Extension Card
CSLC16: 16-Port Single Line Telephone
Extension Card with Caller ID
IP-EXT16: 16-Channel VoIP Extension Card 2.8.36 [1-1] Slot—Card Property - IP
Extension
CSIF4: 4 Cell Station Interface Card
KX-TDA100: 4
KX-TDA200: 4
None
CSIF8: 8 Cell Station Interface Card
LCOT4: 4-Port Analogue Trunk Card
KX-TDA100: 6
KX-TDA200: 8
2.8.10 [1-1] Slot—Card Property - LCO
type
LCOT8: 8-Port Analogue Trunk Card
LCOT16: 16-Port Analogue Trunk Card
DID8: 8-Port DID Card 2.8.30 [1-1] Slot—Card Property - DID
type
BRI4: 4-Port BRI Card
KX-TDA100: 6
KX-TDA200: 8
2.8.13 [1-1] Slot—Card Property - BRI
type/PRI type
BRI8: 8-Port BRI Card
PRI23: PRI Card (23B channels)
KX-TDA100: 4
KX-TDA200: 4
PRI30: PRI Card (30B channels)
T1: T-1 Trunk Card 2.8.18 [1-1] Slot—Card Property - T1
type (KX-TDA100/KX-TDA200/KX-
TDA600 only)
E1: E-1 Trunk Card 2.8.21 [1-1] Slot—Card Property - E1
type
E&M8: 8-Port E & M Trunk Card
KX-TDA100: 6
KX-TDA200: 8
2.8.27 [1-1] Slot—Card Property - EM
type (KX-TDA100/KX-TDA200/KX-
TDA600 only)
IP-GW4 (KX-TDA0480/KX-TDA0484): 4-
Channel VoIP Gateway Card
KX-TDA100: 4
KX-TDA200: 4
2.8.33 [1-1] Slot—Card Property - IP
Gateway
IP-GW16: 16-Channel VoIP Gateway Card
OPB3: Optional 3-Slot Base Card
KX-TDA100: 4
KX-TDA200: 4
2.8.41 [1-1] Slot—Card Property -
OPB3 (KX-TDA100/KX-TDA200/KX-
TDA600 only)
KX-TDA100/KX-TDA200
Card Maximum Quantity Card Programming
