Panasonic KX-TDA100 Pc Programming Manual

2.10 [3] Group
528 PC Programming Manual
2.10.23 [3-8-2] VM(DTMF) Group—Group Settings
A VM (DTMF) group has a floating extension number, and can be assigned as the destination for
redirected calls and incoming calls.
To assign members to the group, click Member List. To view a list of all programmed extension
numbers and types, click Extension List View.
Floating Ext. No.
Specifies the floating extension number of the VM (DTMF) group.
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
2.10.23 [3-8-2] VM(DTMF) Group—Group Settings
Programming Manual References
None
Feature Guide References
1.24.1 Voice Mail (VM) Group
Group Name
Specifies the name of the VM (DTMF) group, which will be shown on the display of extensions that
call the VM (DTMF) group.
Value Range
Max. 20 characters
Maintenance Console Location
2.10.23 [3-8-2] VM(DTMF) Group—Group Settings
Programming Manual References
None
Feature Guide References
1.24.1 Voice Mail (VM) Group
Type
Specifies the initial service mode in which the VPS answers calls.
Value Range
AA, VM

Panasonic KX-TDA100 Specifications

General

System Capacity	Up to 128 extensions
VoIP Support	Yes, with optional cards
Digital Extensions	Yes
Analog Extensions	Yes
ISDN Support	Yes
Power Supply	AC 100-240 V, 50/60 Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Networking	Yes
Type	Hybrid IP PBX
Wireless Capability	Yes
Supported Extensions	Digital, Analog
Trunk Interfaces	Analog, ISDN
Voicemail Capacity	Optional, via voice processing cards
